Help Center30V/80A dc Power Supply,digital dc Power Supply With High Accuracy,Continuous Adjustable Power Supply ,factory dc Power Supply
Related Products
-
30V/50A dc Power Supply,high Power Supply,digital dc Power Supply,Continuous Adjustable Power Supply ,factory dc Power SupplyNegotiableMOQ: 1 Piece -
60V/30A dc Power Supply,high Power Supply,digital dc Power Supply,Continuous Adjustable Power SupplyNegotiableMOQ: 1 Piece
-
30V/100A dc Power Supply,high Power Supply,Continuous Adjustable Power SupplyNegotiableMOQ: 1 Piece
-
dc Power Supply,variable Power Supply,switching Power Supply,superpower Supply,high-power SupplyNegotiableMOQ: 1 Piece
-
LW-K305D pc Power Supply,switching Power Supply,Mini Power Supply,power SuppliesUS$ 28.34 - 30MOQ: 500 Pieces
Specifications
1. Charge batteries, PCB board manufacturing industry2. LED products, motors and dc fans test,
3. high accuracy,slight weight
power supply. For this serial power supply, it has perfect protection circuit, can be used in many areas.
applications:
- 1. Charge batteries, PCB board manufacturing industry
- 2. LED products, motors and dc fans test,
- 3. Electrofacing, electrolyzation, electronic components ageing
- 4. Laboratory , Electronic equipment , Automatic Test Equipment
- 5. All other occasions need to use DC Power Supply
protection function:
- 1. Over voltage protection
- 2. over load protection
- 3. over temperature protection(threshold value:700C -750C)
- 4. current limitation protection
features:
- 1. single phase, single output dc power supply
- 2. constant voltage and constant current operation (C.C and C.V. automatic conversion)
- 3. both current and voltage can be adjusted from 0 to rated value
- 4. 3LED digital display
- 5. Built-in EMI filter.(have anti-interference circuit)
- 6. intelligent temperature control fan to help power supply cooling fast
specifications:
Model No: LW3080KD
Input voltage: single-phase 220V±10% 50Hz or 110V±10% 60Hz
Working conditions: -100C -400C relative humidity :< 90%
Storage conditions: -200C-800C relative humidity :< 80%
Output voltage: 0-30V
Output current: 0-80A
Display Accuracy: ±1%±1 digit
Current stabilization: ≤0.5%
Load stabilization: ≤0.3%
Ripples and noises: ≤1 %( RMS)
Surge Current: 30A/115V, 60A/230V (cold-start)
Input Leakage Current: <0.7mA/230V
Withstanding voltage test:
From input voltage to output voltage: 1.5KVAC/min
From input voltage to case: 1.5KVAC/min
From output voltage to case: 500VAC/min
Model |
Output voltage |
Output current |
display |
Display accuracy |
Dimension mm |
Weight kg |
LW1550KD |
0-15V |
0-50A |
3LED display |
±1%±1 digit |
530*320*220 |
8.5~13 |
LW1560KD |
0-15V |
0-60A |
3LED display |
±1%±1 digit |
530*320*220 |
8.5~13 |
LW3050KD |
0-30V |
0-50A |
3LED display |
±1%±1 digit |
530*320*220 |
8.5~13 |
LW3060KD |
0-30V |
0-60A |
3LED display |
±1%±1 digit |
530*320*220 |
8.5~13 |
LW3080KD |
0-30V |
0-80A |
3LED display |
±1%±1 digit |
530*320*220 |
8.5~13 |
LW30100KD |
0-30V |
0-100A |
3LED display |
±1%±1 digit |
530*320*220 |
8.5~13 |
LW30120KD |
0-30V |
0-120A |
3LED display |
±1%±1 digit |
530*320*220 |
8.5~13 |
LW6030KD |
0-60V |
0-30A |
3LED display |
±1%±1 digit |
530*320*220 |
8.5~13 |
REMARK: WE COULD DO THE PRODUCT ACCORDING TO CUSTOMERS’ REQUIREMENT
