10KHz Digital LCR Meter

10KHz Digital LCR Meter thumbnail-1
10KHz Digital LCR Meter photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
LW
Model Number:
LW2811C
Contact Supplier Request Quote Chat Now
Dongguan Longwei Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name LW
Model Number LW2811C

Specifications

Easy operation, high stability, suitable for testing production field.

Features

Base on single micro-processor, using advanced 5 ports techniques and micro-processor corrected errors.

Impact protection, locking range and special zeroing function.

Easy operation, high stability, suitable for testing production field.

Specifications:

1,Measuring parameters

L ,C,R ,Q,D

2,Measuring frequency

LW2811C:100Hz,1KHz,10KHz±0.02%

LW2812C:100Hz,1KHz,100KHz±0.02%

3,Measuring range

Parameters

Frequency

Measuring range



L

100Hz ,120Hz

1μH~9999H

1KHz

0.1μH~999.9H

10KHz

0.01μH~99.99H

C

100Hz,120Hz

1pF~9999μF

1KHz

0.1pF~999.9μF

10KHz

0.01pF~99.99μF

R



0.001Ω~99.99MΩ

Q



0.001~9999

D



0.0001~9.999



4,Measuring accuracy

Parameters

Frequency

Measuring accuracy

L

100Hz ,120Hz

±[1μH+0.25%(1+L/200H+2mH/L)](1+1/Q)

1KHz

±[0.1μH+0.25%(1+L/200H+0.2mH/L)](1+1/Q)

10KHz

±[0.01μH+0.5%(1+L/10H+0.04mH/L)](1+1/Q)

C

100Hz ,120Hz

±[1pF+0.25%(1+1000pF/Cx+Cx/1000μF)](1+Dx)

1KHz

±[0.1pF+0.25%(1+100pF/Cx+Cx/100μF)](1+Dx)

10KHz

±[0.01pF+0.5%(1+20pF/Cx+Cx/4μF)](1+Dx)

R



±[1mΩ+0.25%(1+R/2MΩ+2Ω/R)](1+Q)

Q

100Hz, 1KHz

±[0.020+0.15(Qx+1/Qx)%]

10KHz

±[0.020+0.2(Qx+1/Qx)%]

D

100Hz, 1KHz

±0.0010(1+Dx2)

10KHz

±0.0015(1+Dx2)

5,Test signal level

0.3Vrms±10% (Empty) @ 1 KHz

6,Testing speed

4-6 times per second

7,Temperature:0°c~40°c

8,Humidity: ≤85% RH

9,Supply voltage

Voltage: AC198V~242V   Frequency: 50Hz±5%

Power consumption :< 30W

10,Volume and weight

Dimensions: LW2812C/2811C : 360×320×140mm

Weigh: about 3.5Kg
