ALMACO China Well Selling Column Moving Surface Grinder

ALMACO China Well Selling Column Moving Surface Grinder thumbnail-1
ALMACO China Well Selling Column Moving Surface Grinder photo-1
US$ 3,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Sand Mill
Product Type:
Perfume
Contact Supplier Request Quote Chat Now
Almaco Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Sand Mill
Product Type Perfume
Place of Origin China
Brand Name ALMACO
Model Number SG50100AHR/AHD
Voltage 380V or as your requirement
Power(W) w
Dimension(L*W*H) mm
Weight kg
Certification ISO9001&CE
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas



Model SG50100AHR/AHD
Table size 500X1000mm
Max grinding  500x1000mm
Max distance from table to spindle center 600mmm
Standard magnetic chuck sizes 500x1000x1mm
Speed of table longitudinal movement 5-25m/min
Wheelhead cross movement auto feed 0.5-20mm/t
Wheelhead cross movement rapid feed 1.25m/min
Wheelhead cross movement feed of handwheel 0.02mm/div
Wheelhead vertical movement auto feed 0.005,0.01,0.015,0.002,0.03,0.04mm/t
Wheelhead vertical movement rapid feed 230m/min
Wheelhead vertical movement feed of handwheel 0.02mm/div
Wheel speed 1450(50HZ),170RPM(60HZ)
Wheel size 355x(20-50)x127
Motor of spindle 7.5kw
Max loading capacity of table 700kg
Total rated power 12kw
Height of machine 2390mm
Floor space 4700x2200mm
Gross weight 5500kg



Standard equipment:

olant tank

2.wheel dresser base

3.flange and wheel extractor

4.standard wheel

5.balance arbor

ing lamp

7.leveling wedge and foundation bolt

8.demagnetization unit

9.PLC auto grinding controller(only for AHD model)

Optional equipment

1.elector magnetic chuck

2.manual parallel wheel dresser

olant tank with magnetic separator

olant tank with paper filter

olant tank with paper filter and magnetic separator
