three coil automatic wire winding machine
1.The device is mainly used for high tension coil of the three-phase synchronous wound.
2.It has variable speed, even and close cable, and good synchronization of three coils.
3.The wire releasing device with constant tension is supplied with electric closing line device as needed.
three coil automatic wire winding machine
|
Item
|
HAW-2 Three coil |
Wire station height |
1300mm |
Insulation paper width |
1700mm |
Spool length |
1900mm |
Spindle center height |
870mm |
Max spindle transfer power |
785(N*m) |
Single coil width |
550mm |
Working speed |
0-120r/min |
Motor power |
7.5kw |
Round wire specification |
Dia 0.5-3.5mm |
Wire precision |
0.01mm |
Device composition
| Spindle box | spindle | Cable station | The wheel frame | |
| Insulating paper decoiler | Wire decoiler | Tension console | Electrical console | Electrical control cabinet |
Factory view
***************************
1.More than twenty years experience of industry products
2.All models with CE , TUV, SGS , ISO9001/9002 OR other authority approved
3.High reputation around the world
4.Professional service and technology support
5.Competitive price with better quality, even the best
6.Final exported products would pass the strict test processing by 3rd international authority BIVAC
7.There is more exporting experience for 20years with our owned manufacture/company
