Help Centerthe Best Sale and Low Price Well and Approved Radial Drilling Machine ZQ3040*13 of China of ALMACO Company
Related Products
-
China Profect and Low Price Well Magnetic Drill Machine J1C32A of ALMACO CompanyNegotiableMOQ: 10 Sets -
China Profect and Low Price Small Bench Drill for Sale SX0 of ALMACO CompanyNegotiableMOQ: 1 Set
-
China Profect and Low Price Cnc Micro Drills 52531 of ALMACO CompanyNegotiableMOQ: 1 Set
-
China Profect and Low Price High Precision Vertical Drilling Machine ZN5025 of ALMACO CompanyNegotiableMOQ: 1 Set
-
the Hot Sale and Low Cost China Valve Seat Boring Machine TQZ8560 of ALMACO CompanyNegotiableMOQ: 1 Set
well and approved radial drilling machine ZQ3040*13
Specifications
1. Hydraulic clamping.
2. Hydraulic transmission.
3. Hydraulic preselection.
4. Electrical machinery double protection
Product Descriptio
With antisticlooking and its general arrangement is very harmonized.
With mechanical gear change, convenient to operate.
With comatic automatic ascent and descent cranking bar and production efficciency is high With confident construction, high precision and durable in use.
well and approved radial drilling machine ZQ3040*13
well and approved radial drilling machine ZQ3040*13
| SpecificationModel | 15170 | 15171 | 15172 | 15173 | 15174 | 15175 |
| Z3032 x 9 Z3032 x 10 |
ZQ3035 x 10 | ZQ3040 x 10 | ZQ3040 x 13 | ZQ3050 x 13 | ZQ3050 x 16 | |
| Max. drilling dia. (mm) | 32 | 35 | 40, 35 | 40, 35 | 50 | 50 |
| Spindle taper | MT4 | MT4 | MT4 | MT4 | 5# | 5# |
| Spindle speeds/steps | 108-1000/6 | 75-1200/6 | 75-1220 | 75-1220 | 80, 135, 240, 350 ,590, 1100 | |
| Distance from spindle center to column surface (mm) |
780-220 | 1000-300 | 1000-300 | 1300-300 | 1300-360 | 1600-360 |
| Distance from spindle center to table surface (mm) |
980-220 | 1000-260 | 1000-260 | 1000-260 | 1050-260 | 1050-260 |
| Spindle travel (mm) | 120 | 180 | 200 | 200 | 200 | 200 |
| Range of spindle feeds (mm) | Optional | 0.10-0.32 | 0.10-0.32 | 0.10-0.32 | 0.10-0.32 | 0.10-0.32 |
| Overall dimensions (mm) | 1320 x 600 x 1900 | 1450 x 700 x 2050 | 1500 x 705 x 2020 | 1700 x 705 x 2120 | 1950 x 810 x 2450 | 2170 x 950 x 2450 |
| Motor (kw) | 0.85/1.5 | 1.1/2.2 | 2.2/0.75 | 2.2/1.1 | 4/1.5 | 4/1.5 |
| N.W. (kg) | 800 | 1100 | 1530 | 2200 | 2700 | 3200 |
Our service:
1.All of our goods will pass QUALITY INSPECTIONS before shipment. Best after sale service, customer can follow their order situation any time, no matter on product line, warehouse or shipment.
2.More than 10 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
3.Special dimensions available according to request.
4.We have many certificates of our Products.
5.Accessories replacement if our product itself has quality problems during one year after receiving.
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
We are looking forward to bulding sincere and long-term business relationship with you
