the best sale and low price china radial drilling machine RD8031 of ALMACO company
- 30 Set / Sets per Month
- shanghai port
- T/T L/C D/P D/A
Product Details
Condition: | New | CNC or Not: | Normal | Place of Origin: | Jiangsu, China |
Brand Name: | ALMACO | Model Number: | RD8031 | Voltage: | 380V |
Power(W): | 7.5kw | Dimension(L*W*H): | 4380*1400*4025mm | Weight: | 11800kg |
Certification: | CE;ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
china radial drilling machine RD8031
Specifications
1.multi-spindle drilling machine
2.flexible reliable
3.perfect feature
4.high precision
5. RD10031 raidal drilling machine
Product Descriptio
The radical drilling machine is suitable for high-speed steel, hard alloy and ceramic cutting tool,
machining inner and outer cylindrical surface, inner and outer conical surface, groove and plane of
ferrous metals, nonferrous metals and some non-metallic parts. It can meet different quantity
production requirements with high efficiency, stable and reliable precision.
Optimum design conforming to international standard.
Key precisely machined parts precision machining
Great Flexible radical drilling machine with reliable and perfect feature
This radical drilling machine has High precision; high strength.
This radical drilling machine has Economical cutting and long life.
Drilling, counterboring, reaming, boring, spotting,tapping.
The radical drilling machine's heat treatment made by first-class equipment, ensuring durability.
The radical drilling machine's main parts and key part are made by high strength cast and special steel material.
The radical drilling machining is made by means of specialized equipment, to ensure basic parts with superior quality.
Clamping for assemblies and speed-change of spindle is achieved by hydraulic power, and is sensitive and reliable.
16 steps of spindle speed and feed brings about economic and high-efficiency cutting.
Mechanical and electrical controls are centralized on the headstock, with easy and rapid operation
Mew paining technology and improved outward appearance reflects the specialty of machines
china radial drilling machine RD8031
china radial drilling machine RD8031
Item | unit | RD10031 | RD10028 | RD10025 | RD8031 | RD8028 | RD8025 | RD8025 | RD8020 | RD8016 | RD6325 | RD6320 | RD6316 | ||
max. drilling capacity | mm | F100 | F80 | F63 | |||||||||||
Distance between spindle axis and column | Max | mm | 3100 | 2800 | 2500 | 3100 | 2800 | 2500 | 2500 | 2000 | 1600 | 2550 | 2050 | 1650 | |
Min | mm | 560 | 500 | 450 | |||||||||||
Horizontal travers of main spindle | mm | 2590 | 2000 | 1600 | |||||||||||
Distance b/w spindle end to worksurface plate | Max | mm | 2500 | 2000 | 1548 | 1600 | |||||||||
Min | mm | 700 | 550 | 348 | 400 | ||||||||||
ARM | lifting distance | mm | 1300 | 1000 | 800 | ||||||||||
lifting speed | m/s | 0.017 | 0.01 | ||||||||||||
swivel angle | ° | 360° | ±180° | ||||||||||||
Main spindle | Morse No. | MT6 | MT5 | ||||||||||||
Strokes | mm | 500 | 450 | 400 | |||||||||||
Speed | scope | rpm | 0,200,160,125,100,80,63 ,50,40,31.5,25,20,16,12.5,1 0,8 | 1250,800,500,400,315,250 ,200,160,125,100,80,63,50, 40,25,16 | 1250,800,500,400,315,250 ,200,160,125,100,80,63,50, 40,25,16 | 1600,1000,630,500,400,31 5,250,200,160,125,100,80, 63,50,32,20 | |||||||||
steps | no. | 22 | 16 | 16 | |||||||||||
Feeding | scope | mm/r | 3.2/2/1.56/1.25/0.8/0.63/0.5 /0.32/0.25/0.2/0.16/0.13/0.1 /0.06 | 3.2/2/1.25/1/0.8/0.63/0.5/0. 4/0.32/0.25/0.2/0.16/0.13/0. 1/0.06/0.04 | 3.2/2/1.25/1/0.8/0.63/0.5/0.4/0.32/0.25/0.2/0.16/0.13/0.1/ 0.06/0.04 | ||||||||||
steps | 16 | 16 | |||||||||||||
Drilling depth per scale | mm | 170 | 151 | 150.8 | |||||||||||
Max feeding force of main spindle | N | 50000 | 35000 | 25 | |||||||||||
Max torque of main spindle | N.m | 2500 | 1568 | 1000 | |||||||||||
Main motor power | kw | 15 | 7.5 | 5.5 | |||||||||||
Lifting motor power | kw | 3 | 3 | 1.5 | |||||||||||
Clamping motors to spindle * arm | kw | 0.75 | 0.75 | ||||||||||||
Coolant pumpt motor power | kw | 0.09 | |||||||||||||
Machine weight | kg | 20000 | 19000 | 18000 | 11800 | 11400 | 11000 | 7400 | 7000 | 6700 | 7400 | 7000 | 6700 | ||
Overall size | mm | 4530/4250/3850x1630x4795 | 4380/4080/3780x1400x4025 | 3610,3110,2710x1250x3437 | |||||||||||
Column diameter | mm | F600 | F600 | F450 (550kg) | |||||||||||
Working table | Size | mm | 1250 x 800 x 560 | 1000x800x560 | 950x630x500(43kg) | ||||||||||
T slot (W x T) | mm | up 28 x 26, down 50 x 51 | up 22 x 23 , down 36 x 39 | up 22 x 23 , down 36 x 44 | |||||||||||
T slot (W x T) | mm | up 28 x 26, down 46 x 48 | up 28 x 26, down 46 x 48 | up 28 x 26, down 50 x 51 | |||||||||||
Base plate | Size | mm | 4280 x 1630 x 330 | 3530 x 1400 x 300 | 2900 x 1250 x 250(2330kg) | ||||||||||
Operation area | mm | 3640 x 1600 | 2890 x 1370 | 2145 x 1250 |
