Home > Products > New Products > Rubber Extruder XJ-115
Rubber Extruder XJ-115
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
This rubber extruder of hot feeding and single screw extruding, with adjustable speed. Changing the head of the machine can obtain various extruding, semi-finished products and forming sheets and filter rubber for coating. It can be used widely in extruding.
Rubber Extruder
Type | XJ-65 | XJ-115b | XJ-120 | XJ-150 | XJ-200 | XJ-250 |
Forms of screw and screw thread | Double-head equal-depth convergent type | Double-head convergent type | Double-head convergent type | Double-head unequal-depth | Double-head convergent type | Double-head convergent type |
Screw diameter(mm) | 65 | 115 | 120 | 150 | 200 | 250 |
Length-diameter ratio of screw(L/D) | 4 | 4.8 | 4.6 | 4.43 | 4.35 | 4.5 |
Compression ratio | 1.3 | 1.34 | ||||
Rotary speed of screw | 5.2~52 | 5.4~54 | 5.6~55.6 | 20~26 | 22.4~67.2 | 19.7~59.1 |
Motor power(KW) | Electromagnetic speed 7.5KW | Electromagnetic speed 22KW | Electromagnetic speed 22KW | FrequencyControl 55kw/motor Commutator18.3-55kw | FrequencyControl 55kw/motor Commutator25-75kw | Commutator 33.3-100 |
Production capacity(kg/h) | 50~80 | 100~420 | 100~450 | 700~1200 | 1500~2200 | 2000~3200 |
Steam pressure(Mpa) | 0.2-0.3 | 0.4-0.6 | 0.2-0.4 | 0.6 | 0.6-0.8 | 0.6-0.8 |
Coolingwaterpressure(Mpa) | 0.2-0.3 | 0.2-0.3 | 0.2-0.4 | 0.2-0.3 | 0.2-0.3 | 0.2-0.3 |
Size(length×width×height)mm | 1750×550×1100 | 2427×750×1330 | 2427×750×1330 | 3411×814×1470 |
