Kaplan Water Turbine/Axial Flow Hydro Turbine
The Kaplan (axial-flow) turbine for low head from 2m to 70m. This type of turbine is mostly suitable for hydropower stations with low water head and big flow.
lts feature is that the water flow passes through the runner axially. The axial-flow turbine can be classified into two forms according to the runner construction: one is fixed blades (Propeller) for small variation of head and power, the other is movable blades (Kaplan) for large variation of head and power.
The kaplan turbine with vertical shaft arrangement , with three types as open flume, pressure flume, and seal off (concrete spiral case).
Generally, Kaplan turbine is composed of distributor, guide vane, runner, draft tube etc.
Application:
1 Type: Kaplan with fixed blades/Kaplan with movable blades
2 Water head: 2m -- 70m.
3. Installation capacity: 100KW -- 5MW
4. Frequency: 50/ 60hz
5. Runner blades material: Stainless steel (0Cr13Ni4Mo)
6. Water head: 2m -- 70m
7.Output Type: 0.4KV, 3.3KV, 6.3KV, or 10.5KV AC three phase,
8. Frequency: 50/ 60hz
9. Generator type:Synchro generator
10. Auxiliary Equipment: Governor, Inlet Valve, unit side panel, excitation system
11. Output Type: 0.4KV, 3.3KV, 6.3KV, or 10.5KV AC three phase,
Kinder Reminder:
If you are interested in the Kaplan turbine, you should have some key parameters (such as net head, flow discharge, unit number, frequency, voltage) in inquiry.
