S-180W LED Non-waterproof Power Supply

Name: S-180W LED Non-waterproof Power Supply
Brand: Zoyea
SKU: 115105237
Availability: InStock

US$ 2.45 - 13.3 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Zoyea

Model Number:

S-180W

Shenzhen Zoyea LED Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Zoyea

Model Number S-180W

Output Power Other, 180W

Output Type Single

Input Voltage Other, 90~264V

Output Voltage 12,24V

Output Frequency 47~63

Output Current 0.25~3A

Specifications

LED non-waterproof power supply
1.Ac-Dc Standard series Single-output
2.Output Power around 15~400W
3.Voltage around 12~24V

Product Electric Parameters
Input specification	Input voltage			AC90V---264V
	Input frequency			47-63Hz
	Input surge			20A@120VAC 40A@230VAC
Output specification	Output voltage can be adjusted			±10%
	Start-up time			≤1S(input230V,Io=100%)
	keep time			≥20mS (input230V,Io=100%)
	Voltage regulation			(Full load) ≤0.5%
Protection function	Overload protection			105% - 150% rated power, automatic recovery
	Over-voltage protection			105% - 150% of the rated voltage
Insulation intensity	Input---output			1500VAC/1min
	Input---ground			1500VAC/1min
	Input---ground			500VAC/1min
Safety standards	According with GB4943, UL60950-1,EN60950-1 standards.
E M C standards	According with GB9254, EN55022 class A EN61347-2-13:2008 standards
Environmental	working temperature		- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
	Storage temperature		- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
	height above sea level		≤2000M
Structure	Size(mm)		199(L)98(W)38(H)
Cooling method	Cooling method		Natural cooling air convection
Weight	0.6KG/PCS
Product Type Table
Product model		output specification		ripple, noise	efficiency
S-180-12		12V	15A	100mV	80%
S-180-15		15V	12A	100mV	80%
S-180-24		24V	7.5A	100mV	80%
S-180-36		36V	5A	100mV	80%
S-180-48		48V	3.75A	100mV	80%
