Help CenterIntelligent Hot Air Seam Sealing Machine F-8+/F-8
Related Products
Specifications
ingelligent ho air seam sealing machine-the Best choice for premium BrandsProduct Specifications
Model: F-6
Voltage: AC 220V
Frequency: 50/60Hz
Power consumption: 3600W (max.), 1500W (standard)
Compressed air: 0.4-0.6MPa (4-6Kg)
Seaming speed: 2-16m/minute
Blast nozzle temperature: 50-700°C
Blast nozzle device: 22.0mm (standard), other optional
Upper whorl width: 25.4mm
Lower whorl width: 30mm
Total volume: 0.6m (w) ×1.2m ×1.77m (h)
Total weight: 165Kg
The performance may change as a result of continuous improvement and no further notice will be provided.
=> Key Performances of the Product
1. Fully computerized blast nozzle positioning system, which can be controlled through the touch screen directly and ensure 100% repeatability of the movements.
2. 3D swing gun movement structure system, making the operation more humanized and further enhancing the product quality.
3. Upper and lower rubber wheel differential system, solving the problem of folds caused by stretching or bending of the fabric.
4. Real-time speed regulation system. When there is curves part or cross bone part, the speed can be adjusted instantly so that the adhesive tape can better fit the material and enhance the water-proof effect.
5. Blast nozzle real-time adjustment system. The angle of the blast nozzle can be adjusted to fit all kinds of adhesive tapes and materials.
6. Blast nozzle swing-in (out) arc adjustment function.
7. Blast nozzle swing-in lifting or lowering function, fully solving problems such as tape head, tape tail, loose adhesion and goffer, etc.
7. Upper rubber wheel lifting (suspension) system with advanced design mode. When the process of adhesion of ultrathin materials is paused, it can reduce the pressure automatically and thus eliminate pressing marks.
8. PLC computer function memory system, in which various blast nozzle positions can be saved for future repeated use.
9. Self protection system. When the air flow is too low, the heating process will be stopped or prevented automatically, so that the user can operate this device more safely and the life span of the heating coil can be effectively extended.
10. Adhesive tape consumption memory system, which can calculate the amount of adhesive tape consumption. Unit: m.
11. Intelligent tape release system, preventing deformation of adhesive tape in operation and enhancing the quality of adhesion.
12. Independent conveyor belt system with an independent motor, presenting a more accurate and perfect conveying effect.
13. 80% of the device is made of aluminum alloy and all parts are machined precisely with CNC.
14. Brand-new imported color touch screen control.
15. The device adopts an imported step motor of a famous brand and a step belt drive structure.
16. Swing gun structure with the telescopic system, making it easier, faster and safer to load and clamp the adhesive tape.
17. Step motor, realizing the principle of swing gun movement.
18. Strengthened base with rolling wheels.
19. Brand-new appearance design.
