Specifications
Vertical Form Fill Seal Machine1.Inclined forming set with gentle handling to fragile products
2.Automatic pneumatic air purg
Vertical Form Fill Seal Machine
Feature:
1.High standard packaging machine made in stainless steel
2.New model design and production according to European standard
3.Servo driven film pulling system ,full servo is option
4.Photo sensor for automatic tracking eye marks
5.Inclined forming set with gentle handling to fragile products
6.Smooth and fast film releasing by advance tension control
7. CE mark with safety guard doors
Application:
VFFS Inclined series is a vertical form fill seal machines with incline forming tube and construction, which is a good solution for packaging fragile products, such as biscuits, pastries, baked goods and other brittle products in general.
Machines parts and system accessaries :
1.Material feeding funnel
2.Film roll unwinding system with motorize control
3.Date printing device
4.Encoder bag length control and eye-mark tracking
5.Bag forming, filling and sealing
6.Bag cutting and finish bag exit
Key Features of VFFS:
1.Servo motor driven pull belts
2.PLC based, 7 inch touch screen parameter adjustment
3.Pneumatically operated horizontal sealing jaws
4.PID digital temperature control
5.Motorized film unwinding system
6.Encoder bag length control
7.Photo cell for bag eye-mark registration
8.One forming assembly for fast changeover bag size, no tools need.
9.Safety guard with safety switch
10.Air regulator, filter and lubricator
11.Automatic pneumatic air purge
Benefits and Advantages for Complete system:
1.Solid performance, excellent packing quality, great user experience
2.Reliable and compact, the simple design of the baggers make them easy to set-up, operate, and maintain.
3.One of the most affordable baggers on the market, the series offer great value with an excellent ROI.
4.Designed for low cost of maintenance using off-the-shelf parts. Interfaces easily with auxiliary equipment.
Technical Data:
Model |
VFFS-500 |
|
Frame structure |
Stainless steel |
|
Film width |
Max.500mm |
|
Bag width |
80-240mm |
|
Bag length |
50-300mm |
|
Packing speed |
Max. 60 bpm |
|
Power supply |
220V, 50HZ, 4Kw |
|
Air requests |
0.3m3/min, 0.6Mpa |
|
The bag sample :
High quality machine photo:
