Specifications
hard alloy disc cutter1.exceptional performance
2.expanded productive life
3.high grade quality materials
disc cutter, rond cutter
1.exceptional performance
2.expanded productive life
3.high grade quality materials
4. Long life time.
5. High hardness and wear resistance.
6. OEM&ODM.
7. Factory reasonable price.
Located in Liyu Industrisl Area, Zhuzhou City, Tianyuan District, Hunan Province, Zhuzhou Mingri Cemented Carbide Co., Ltd was established in May of 2001 with the investment of RMB 40 million. We own up-to-date production line, advanced equipment, lots of technicians. We have passed ISO 9001:2008 ,ISO 9001:14001. And we have been always trying our best to provide our customers with high quality, best price and satisfactory services.
We specialize in series of tungsten carbide products, such as cold forging die cores, brazed tips, disc cutters, plates and boards, saw tips, round rods, rock drilling bits and buttons, milling tools, geological exploration drill tools and so on. Our products are exported to UK, European, Japan, Taiwan and South-east Asia etc.
We are manufacturer, not just trade!
Welcome to have a visit to our factory!
Address No: 88 Mingri Road, Liyu Industrial Area, Tianyuan District, Zhuzhou City, Hunan Province, China.
1. Grade of cemented carbide circular milling cutters
Grade |
Equal to ISO Category Number |
Performance |
uses |
||
Density |
Bend Strength |
Hardness |
|||
G/Cm3 |
N/mm2 |
HRA |
|||
YG3 |
K01 |
14.9-15.3 |
≥1180 |
≥90.5 |
sand-blasting nozzlesQualified for fine turning and half-fine turning when cast iron, non-ferrous metal, alloys as well as non-alloy materials cutting consecutively. Can make wire drawing of steel and non-ferrous metal. Also qualified for sand-blasting nozzles. |
YG3X |
K01 |
15.1-15.4 |
≥1300 |
≥91.5 |
|
YG6X |
K10 |
14.8-15.1 |
≥1560 |
≥91.0 |
Qualified for machining of chilled cast iron, alloy cast iron, refractory steel and alloy steel. Also Qualified for the machining of common cast iron. |
YG6A |
K10 |
14.7-15.1 |
≥1580 |
≥91.0 |
|
YG6 |
K20 |
14.7-15.1 |
≥1670 |
≥89.5 |
Qualified for finish machining and semi-finish machining for the cast iron, non-ferrous metal, alloy and unalloyed materials. Also qualified for wire drawing for the steel and non-ferrous metal, electric drill for geology use and steel drill etc. |
YG8 |
K20-K30 |
14.6-14.9 |
≥1840 |
≥89 |
Qualified for rough machining of cast iron, non-ferrous metal, nonmetal materials, drawing of steel, non-ferrous metal and pipes, various drills for geology use, tools for machine manufacture and wearing parts. |
YT15 |
P10 |
11.1-11.6 |
≥1180 |
≥91.0 |
Qualified for rough machining, semi-finish machining and finish machining during consecutive machining of carbon steel and alloy steel. |
YT14 |
P20 |
11.2-11.8 |
≥1270 |
≥90.5 |
Qualified for rough machining for rough face of carbon steel and alloy steel, half process during discontinuity cutting. |
YT5 |
P30 |
12.5-13.2 |
≥1430 |
≥89.5 |
Qualified for rough machining for rough face of carbon steel and alloy steel and discontinuity cutting. |
YW1 |
M10 |
12.7-13.5 |
≥1180 |
≥91.5 |
Qualified for finishing and semi-finishing machining of refractory steel, high manganese steel and common steel. |
YW2 |
M20 |
12.5-13.2 |
≥1350 |
≥90.5 |
Qualified for semi-finishing machining of refractory steel, high manganese steel and common steel. |
2. Detailed description of k20 cemented disc cutters without teeth:
The thinnest is 0.5mm, the biggest diameter is 350mm.
Q: What are your advatantages?
We Zhuzhou Mingri:
a. We have the richest molds stock of cold forging dies.
b. 10 years of stable relationship with our customers.
c. The most advanced tooling house.
d. The largest production capacity, fastest delivery and excellent quality.
e. The most reliable testing machines for all specifications.
f. The best and reliable after service.
Q: What about the transportion?
We Zhuzhou Mingri: It depends on your requirement. We have cooperated with some transportation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port. If you got transportation company, sending them to our factory to pick up products is ok.
Production Process:
Quality Control:
Certifications & Honors:
Our Main Products:
Any detailed information needed, please feel free to contact me! I will reply to you ASAP!!!
Teresa Chou
Mobile:+86 15897337625
Skype:teresa110625
Oversea sales department.:
Tel: 0086-731-22778-506
Fax: 0086-731-22778-510
Company name:Zhuzhou Mingri Cemented Carbide Co., Ltd.
Address:88# Mingri Road ,Liyu Industrial Area, Tianyuan District,Zhuzhou City, Hunan Province, P.R.China Postal code: 412007
