High Quality Laboratory Lab Scissor Jack ,Travel90mm
Model Number |
02DS90 |
Travel |
90+/-2mm |
Dimension |
220mmx140mm |
Driver |
Lead screw |
Guide |
Sliding Guide |
Stepper Motor(1.8°) |
SST42D2121 |
Material |
Aluminum |
Surface Treatment |
Black-Anodized |
Loading |
5kg |
Weight |
10kg |
Min Adjustment |
5μm(non-MS drive) 0.25μm(20-MS drive) |
Max Speed |
5mm/sec |
Repeatability |
10μm |
Backlash |
4μm |
Features:
*Regular stage sets with stepper motor and RS232 interface, can connect with motion controller conveniently.
*Fork type mechanical structure for lifting with high stability.
*High accuracy lead screw for high performance and smooth moving
*Mounting holes both on the top and bottom of table for combine with other stages easily
*The stages can be redesigned.
