High Performance Motorized Lab Jack travel 300mm
- 500 Piece / Pieces per Month
- tianjin port and others
- Credit Card
Product Details
Place of Origin: | Hebei, China | Brand Name: | Memory | Model Number: | 03DS300 |
Product Description
High Performance Motorized Lab Jack travel 300mm
Model Number | 03DS300 |
Travel | 300+/-2mm |
Dimension | 400mmx200mm |
Driver | Lead screw |
Guide | Sliding Guide |
Stepper Motor(1.8°) | SST57D2121 |
Material | Aluminum |
Surface Treatment | Black-Anodized |
Loading | 50kg |
Weight | 23kg |
Min Adjustment | 0.75μm(non-MS drive) |
Max Speed | 10mm/sec |
Reduction Ratio | 1:25 |
Repeatability | 4μm |
Backlash | 3μm |
Features of Motorized Lifting platform:
*Regular stages set with stepper motors and RS232 interfaces, can connect with motion controller conveniently.
*Orthogonal changement and muti-axis support mechanical structure for lifting with high stability.
*High accuracy lead screw for high performance and smooth moving
*Mounting holes both on the top and bottom of table for combine with other stages easily
*The stages can be redesigned.
main product:
the drawings:
We are a professional factory:
