Help CenterHigh Performance 30T/D Soybean Oil Solvent Extracting Equipment
Related Products
-
High-quality 100t/d Soyben Oil Solvent Extraction EquipmentUS$ 214,300 - 225,000MOQ: 1 Plant -
10 Tons per Day Mini Rice Bran Oil Mill PlantUS$ 80,000 - 180,000MOQ: 1 Set
-
Manufacturer Supply 80t/d Cotton Seed Cake Solvent Oil Extraction PlantUS$ 154,300 - 195,000MOQ: 1 Plant
-
200t Vegetable Oil ExtractionUS$ 8,000 - 800,000MOQ: 1 Set
-
Soybean Solvent Oil Extraction MachineUS$ 80,000 - 180,000MOQ: 1 Set
| Technical Description: |
| The complete extraction equipment is applicable to extract oil from the adopt expanding and extracting technical. Pre-dealing expanding technical break the oil cell structure, passivate the enzyme in the oil-cake/flake. Squeezing and expanding to the mould make the contacted area bigger with solvent, so as to make for extraction from expanding materials (cake, embryo). The extraction technical generally extract oil from cake and embryo by pre-extraction or direct extraction. The whole equipment is composed of solvent extracting, wet meal roast & desolventing machine, long pipe evaporator, discal stripper, condenser and other equipment, and it’s matched with explosion proof motor, various kinds of connected pipes in plant, as well as the required accessories of instrument, apparatus, valve and so on.
Applied to : oil-cake/flake, such as soybean, cotton seeds, rapeseeds, maize embryo, rice bran, etc.
Project scope: Complete set of turnkey project
daily treatment : 20t,30T,50T,80T,150T,200T,450T,600T,800T.
main equipment: extractor system, toasting system, DTC desolvent-toaster , evaporation system. steam-stripping equipment, condensing system, exhaust gas recovery system, and so on.
features: 1.it is the most simplified structure of the same type if extractor.
2.replaced with a false bottom plate fixed grid, reducing the movement mechanism, high safe operation rate, work reliably.
3.has a " salf-clesning " effect, clean up grid plate without downtime.
4.it can increase the leaching time of the material, reduce meal residual rate.
5.it can increase the loading factor, increase production
|
|
We have different models in accordance with your requirements,if any questions you have,pls contact me freely.
