Single Shaft Auto Cutting Machine

Single Shaft Auto Cutting Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Other, wooden container
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Machinery & Hardware
Packaging Type Other, wooden container
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Pneumatic
Power 5HP
Place of Origin Jiangsu, China
Brand Name YUYU
Model Number 701

Specifications

1.suitable for various log roll materials
2.PCL rogrammable cotrol
3.Max.cutting speed:35cuts/min
4.Blade speed:360-1800rpm

YU-701 single shaft auto cutting machine

1.Application field:

Suitable for cutting various log roll materials such as lnsulation tape,polyester tape,PVC,OPP,PE,Masking tape,Double-side tape,Plastic films...etc.



 2.Technical Parameters

Max. diameter material

270mm(300 mm)

Max. cutting speed

35 cuts/min

Max. length of cut

1300 mm

Inside diameter of paper core

32—76.2 mm

Range of cutting width

3 ----1300 mm

Main motor

5 HP

Blade drive motor

3HP*6P(servo motor)

Blade diameter

150—350 mm

Blade speed

360---1800 rpm

Weight

1150 kg

Machine dimesion(L*W*H)

2850*1430*1520 mm
