Specifications
bopp tape slitting machine is suitable for BOPP/OPP adhesive/ Glass paper tape/cellophane paper with high speed.
;
1.Application field:
Suitable for BOPP/OPP adhesive/ Glass paper tape/cellophane paper
2.Features:
1. Crowned stretch roll: adopt “pulling flat board” device to eliminate the corrugated phenomenon in the course of sending materials of adhesive tapes.
2. centralized control panel for easy operation. Control operation speed by variable frequency and variable speed.
3. three-step length setting provides extremely smooth rewinding operations to give accurate rewinding length.
4. Automatic four-shaft exchange is adopted. Once rewinding operation is completed, the machine will automatically perform shaft changes.
5. Pneumatic braking is to control the unwind tension. The rewind tension is controlled by the clutch and independent slide setting for free adjustment of the tensile force.
6. Pneumatic brake: bring the machine to an immediate halt and accurate positioning.
3.Technical parameters:
valid width |
1000mm/1300mm/1600mm |
|
Max. unwinding diameter |
600mm |
|
slitting width |
12-1280mm |
|
I.D of paper core |
76.2mm |
|
rewinding I.D |
four shafts rewind |
76.2-150mm |
two shafts rewind |
76.2-300mm |
|
blade |
0.2*22*60mm |
|
machine speed |
0-180M/min |
|
main motor |
5HP |
|
