2013 Newly-developed Efficient Crude Oil Vertical Leaf Filter Machine

2013 Newly-developed Efficient Crude Oil Vertical Leaf Filter Machine photo-1
US$ 1,500 - 7,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, Oil filter
Type:
Other, Oil filter
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Usage Other, Oil filter
Type Other, Oil filter
Automatic Grade Automatic
Place of Origin Henan, China
Brand Name Dingsheng
Model Number NYB-2
Voltage 220V/380V
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas

Specification



1.unique-designed

2.used for multiple purpose

3.easy to operate and maintain

4.raw material is carbon steel



Features:



1.Unique-designed halftone to reduce the cost of flitering

2.Totally enclosed filtering,no oil waste

3.Dregs falling down automatically by vibrating to cut down labor intensity

2013 Newly-developed Efficient Crude Oil Vertical Leaf Filter Machine 2013 Newly-developed Efficient Crude Oil Vertical Leaf Filter Machine

2013 Newly-developed Efficient Crude Oil Vertical Leaf Filter Machine

Hot sale! Vertical Leaf Crude Oil Filter with high quality





leaf filter/decoloring oil filter/crude oil filter





Working Principle



1.Wire gauze+filteraid+pressure

2.The wire gauze consists of frame and many layers of mat wire mesh

3.The decolorizer forms a filter-conductivity layer on the halftone in the process of filtering of normal filtering



Fuctions:

It can be used for bleaching filter and crude oil filter of salad oil and cooking edible oil



Thchnical Parameters:



parameter of crude oil leaf filter

Model

Filter area

Working pressure

Working temperature

Filtering cylinder volume

Diameter of barrel

weight

size

(m2)

(Mpa)

(C)

(L)

(mm)

(Kg)

(mm)

NYB-2

2

0.1~0.4

≤150

120

400

300

620×600

NYB-4

4

250

500

400

770×740

NYB-7

7

420

600

600

1300×1000

NYB-10

10

800

800

900

1500×100

NYB-12

12

1000

900

1100

1600×1250

NYB-15

15

1300

1000

1300

1700×1400

NYB-25

25

1700

1100

1700

1700×1400

NYB-30

30

2300

1200

2500

2000×1550

NYB-36

36

2650

1200

3000

2000×1550

NYB-40

40

2900

1300

3200

2100×1600

NYB-45

45

3200

1300

3500

2100×1600

NYB-50

50

3800

1400

4000

2200×1650





 If any questions you have,pls contact me freely.
