Paper,Plastic Packaging Material and New Condition Adhesive Tape Making Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Power:

Upon customer's request

Taicang Yuyu Plastic Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Power Upon customer's request

Specifications

1.For coating bopp tape.
2.Coating width:500-1600mm
ating speed:250m/min.
4.Coater:comma coater,Mayer bar Caoter

Bopp Adhesive Tape Coating Machine

Specification

1. High-efficiency axial fan oven, drying efficiency, and multi-segment temperature

control, precise control of process requirements under paragraphs oven temperature.

2. Tension segment control, frequency control or digital DC speed control system and

synchronized multi-point controller, the machine synchronous operation.

3. EPC corrector used, ensure that the finished edge of the neatly.

4. Keep volumes can be automatically off of cloth fabric, paper, non stop to achieve

high production efficiency.

5.Plastic coating on the wire rod, high precision, saving glue.

Technical parameters:

Model	YU-500	YU-1000	YU-1300	YU-1600
Valid width	500mm	1000mm	1300mm	1600mm
Mechanical speed	5-60m/min	5-150m/min	5-220m/min	5-220m/min
Coating average degree	0.01mm
Rewinding edge smooth	2mm
Total mechanical speed	20-25HP	20-65HP	30-100HP	40-100HP
Oven length	design upon the request of the customer
Heating	steam/hot blast/thermal oil/electric
Power supply/voltage	380v 50HZ

Main equipment:

Item	Quantity
Supporting Frame&accessories	1 set
Duplex Unwinder&automatic Edge machine	1 set
Mayer-bar Coater	1 set
7 zones oven(4m/zone)(Not Certain,according to Machine speed)	28 m
EPC correction group(out of Oven)	1 group
Cooling Group	1 group
electrical control system	1 set
Duplex Rewinder	1 group
Secondary side piping	1 set
Secondary wiring	1 set
Secondary duct	1 set
