Safe and Reliable High-speed Aluminum Laminating Machine

Safe and Reliable High-speed Aluminum Laminating Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Machinery & Hardware
Packaging Type Case
Packaging Material Wood
Automatic Grade Automatic
Driven Type Mechanical
Place of Origin Jiangsu, China
Brand Name YUYU
Model Number C2
Weight 30T
Certification CE/ISO
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Producing adhesive tape, such as Aluminum foil Release paper/BOPP,PVC,PE tape /Double-side tape/Kraft paper /label sticker/Foam

Feature:

  1. Mesh bottom glue with active smoothing device, straight-scraping transfer printing type gluing, laminating all kinds of materials.
  2. Wide application and simple structure with stable and simple operation.
  3. double-station pneumatic unloading and rewinding
  4. Auto roll changing, auto cloth cutting and film connection.
  5. full- automatic tension control
  6. The temperature is controlled in stages and can be adjusted different request.
  7. The oven is dried by narrow nozzle blasting with high efficiency.

Technical parameters:



valid width

500mm

1000mm

1300mm

1600mm

mechanical speed

5-30m/min

5-80m/min

15-150m/min

15-150m/min

coating average degree

±0.025mm

rewinding edge smooth

±3mm

maximum power

5-25HP

20-45HP

30-80HP

40-100HP

oven length

Upon customer's request

heating method

steam/Hot blast/Thermal oil/Electrical heater
