Plastic Blister Packing Film, Pharma-grade PVC/PVDC Coated Film, Rigid PVC Film For Blister Pack

FOB Price

USD $0.5 - $1.88 / Kilogram

200 Kilograms(Min.Order)

Supply Ability 1000 Kilogram / Kilograms per Month
Port Shanghai
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Material:	PVC	Type:	Other, Blister Packing Film	Usage:	Packaging Film
Feature:	Moisture Proof	Hardness:	Rigid	Processing Type:	Multiple Extrusion
Transparency:	Transparent	Place of Origin:	Liaoning, China	Brand Name:	SINOPES
Model Number:	PVDC

Product Description

Plastic Blister Packing Film, Pharma-grade PVC/PVDC Coated Film, Rigid PVC Film For Blister Pack

Medicinal PVC/PVDC coated film is firstly development and use by German factory in the 1940s. In practical application process, PVDC has good obstruct ability , it plays a good moisture-proof effect to the product in packing.

PVDC material itself is the latex character, has quite big brittleness after the solidification. In the coating process and post-processing, the pivotal technical is to reduce its brittleness, make it normally used in the room temperature environment. Before, the technical ability is too poor to do so. That is one of the technical difficulties of PVDC compound material.

On the basis of oversea craft brother's experience, our technician first produces successfully in China. It mainly takes PVC film as the basal material, then coated PVDC(import from BASF in Germany). During the production processing, the temperature, coated quantity and times and other important considerations are checked strictly to make the final product meet the foreign products quality standards. The obstruct ability is 5 times higher than the common PVC. Meantime it has a certain rigidity, flexible and can be widely used in packaging various solid medicine, especially for easy humidity absorb medicine.

Remarks:

According to the investigation, presently 80% medicine using such packaging materials, but the PVC film that widespread used in China could infiltrate the gas and liquor 6 months later in the room temperature condition. It has a great impact on the product. But if using PVDC, the period for protection can really reach at least 2 years.

A. Technology parameter

The examination result compilation
Item			Technology requirement	Result	Verdict
Facies			Should be colorless and transparent ,even equal ,unallowed corrugation ,oil spot , foreign matter,perforation ,impurity .the crystals not allowed appears above1.3 mm, not exceed three granules in 1.3mm and below 1.3mm per 100cm²	Accord prescribe	Accord prescribe
Distinction	Infrared atlas		The result should be consistent when pvc and pvdc compare with the atlas, separately .	Accord prescribe	Accord prescribe
	Color change		Pvdc surface appears orange, pvc surface color has no change	Accord prescribe	Accord prescribe
PVDC coated quantum			40g/m²±7%	+0% 40g/ m² -3.9%	Accord
Physics capability	Vapor permeation quantity		≤0.8g/( m² ·24h)	0.3 g/ m² ·24h)	Accord
	Oxygen permeation quantity		≤3.0cm³/( m² ·24h·0.1MPa)	1.6cm³/( m² ·24h·0.1MPa)	Accord
	Elongate intensity		≥40MPa	lengthways:55Mpa landscape :54 MPa	Accord
	Strike intensity		Not exceed than two samples damaged out of five samples in landscape orientation and lengthways ,separately	landscape orientation : no damage lengthways :no damage	Accord
	Heat up extend and draw back		Within ±6%	Lengthways:-2.2% landscape:+0.5%	Accord
	Heat up conglutination intensity		≥6.0N/15mm	7.1N/15mm	Accord
Solvent remnant allowance			≤10mg/ m²	Not test out	Accord
Pvc monomer			≤1ug/g(subter-millionth)	<1ug/g	Accord
Pvdc monomer			≤3ug/g(subter-millionth)	<0.1ug/g	Accord
Separate out of diffluence	Clear degree		Solution should be clear,if turbidity ,not allowed heavier than No2 Turbidity standard	Accord prescribe	Accord
	Facility oxide		The tolerance of the Consumption Of The water steep and the blank solution ≤2.0ml	1.1ml	Accord
	Heavy metal		Subter-millionth	Subter-millionth	Accord
	Fixed matter	Water steep	≤30.0mg/100ml	5.2mg/100ml	Accord
		65% Ethyl Alcohol solution	≤30.0mg/100ml	4.4mg/100ml	Accord
		hexane solution	≤30.0mg/100ml	4.2mg/100ml	Accord
Animalcule	Amount of Microbe		≤1000/100cm²	≤30/100 cm²	Accord
	Amount of Mildew and Microzyme		≤100/100cm²	≤30/ 100 cm²	Accord
	Amount of coliform		No check out	No check out	Accord
Abnormity toxicity			In order	Accord prescribe	Accord

B. Use parameter (our product is different from other supplier’s)

Blister temperature: 80℃— 120℃, normally 5℃ higher than PVC , Sealing temperature 170℃— 180℃

Negative pressure: 2.4
