Automatic PLC Controlled Piston Filling Mchine, Filler for Glue, Piston Honey Filling Machine Filler

Automatic PLC Controlled Piston Filling Mchine, Filler for Glue, Piston Honey Filling Machine Filler photo-1
US$ 1 - 5,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
Barrel, Bottles, Cans
Payment & Shipping
Payment Methods:
Port of Shipment:
Any Port of China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type Barrel, Bottles, Cans
Packaging Material Glass, Metal, Plastic, Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 220V/380 or Customization
Power 1.2KW
Place of Origin Liaoning, China
Brand Name SINOPES
Model Number See Details
Weight 1000KG
Certification CE, GMP, ISO9001, FDA
After-sales Service Provided Engineers available to service machinery overseas

Product Description



Automatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine filler

Automatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine filler





Major Characteristics

This is our newly developed filling machine.It has reached the internationl advanced level,partial has exceeded the similar product .It is abroad,also certified by the world famous chemical magnate.This is a inline piston filling machine for cream and liquid.It adopts PLC and touch screen control panel for control material.It is characterized by accurate measuring,advanced structure,stable operating,low noise,large adjusting range,fast filling speed.It is also suitable for the filling of easy volatilization, easy bubbly liquid strong corrosive liquid for rubber,platic,and high viscosity liquid,semi-liquid.Operators adjust and meter figure in the touch screen control panel,also can adjust metering of each filling head.Theexternal surface of this machine is made of excellent atainless steel.Good appearance,applied to GMP standard.



Type Heads Suitable bottles Capacity(bottle/hour) Precise Dimension Power Power source Air source Note
26D 26 Height: 50mm-250mm
Diameter: Φ30mm-Φ100mm
200ml:≤10000 ≤1000ml:±2ml
100-500ml:±1ml ≥500ml:±1%
2000*1500*2000 3 AC 220V;50HZ 0.6MPa Customize: bottleneck
<Φ18
20D 20 200ml:≤8500 2000*1100*2100 2.5
16D 16 200ml:≤6500 2000*1300*2200 4.5
12D 12 200ml:≤6000 2000*1100*2200 1.5
10D 10 200ml:≤4200 2000*1100*2000 3
8D 8 200ml:3500 2000*1100*2100 2.5
6D 6 200ml:3000 2000*900*1800 2
4D 4 200ml:≤1600   3



Samples



Automatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine fillerAutomatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine filler



Automatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine filler


Company Information





Our Workshop

Automatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine fillerAutomatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine fillerAutomatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine fillerAutomatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine filler




Our Services



We will design the machine up to your special request and assure every machine you choose from us is the right and best one.



Automatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine filler




FAQ





More questions, could you pls feel free to find us at any time!



Automatic PLC Controlled Piston Filling Mchine, Filler for glue, piston honey filling machine filler
