Automatic Capsule Filling Machine, Capsule Filler, Semi Automatic Capsule Filling Machine
US$ 1 - 13,888
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
Capsule
Payment & Shipping
Payment Methods:
Port of Shipment:
Any Port of China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Semi Automatic Capsule Filling MachineUS$ 1 - 5,500MOQ: 1 Set -
Semi-automatic Capsule Filling MachineUS$ 1 - 4,999MOQ: 1 Set
-
NJP-3500/2000A/C Automatic Capsule Filling MachineUS$ 1 - 28,888MOQ: 1 Set
-
NJP-200/400/800/1200 Automatic Capsule Filling MachineUS$ 1 - 5,000MOQ: 1 Set
-
0-5# Capsule Filling MachineUS$ 1 - 2,999MOQ: 1 Set
Condition
New
Application
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type
Capsule
Packaging Material
Other, Hard Capsule
Automatic Grade
Automatic
Driven Type
Electric
Voltage
220V/380V or customization
Power
3.5KW
Place of Origin
Liaoning, China
Brand Name
SINOPES
Model Number
NJP
Dimension(L*W*H)
1350x1020x1850mm
Weight
850KG
Certification
CE, FDA, ISO, GMP, IQ, OQ, PQ docs can be supplied
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Automatic Capsule Filling Machine, Capsule Filler, Semi Automatic Capsule Filling Machine
Fetures
- Accurate orientation, Capsule vacuum positioned mechanism to make the capsule upload percentage over 99%.
- Freely adjusting dosage, easy speed selection and closed capsule length adjustment.
- PLC program control panel with LCD touching screen operation, and monitoring function.
- Displaying in-time speed and accumulative output.
- Auto-trouble shooting, lack of material, lack of capsule, block in material channel and other mechanical trouble with be show on HMI ,Machine stop
- Electrical Appliance control system approved to CE, and international standard.
- Quick and accurate change part set-up, easy to remove rotary table and ring carrier assembly.
- Fully enclosed dosing stations and rotating table for integration of the whole capsule filling plants.
- The working station cam runs under the good lubricating condition, extends the operating life of change parts. All the Precious are made by USA HASS and DMG CNC machine.
Technical Data
Model |
NJP500 |
NJP800 |
NJP1200 |
NJP1500 |
Output |
30000 |
48000 |
72000 |
90000 |
No. of dieorifice |
4 |
6 |
9 |
12(double line) |
Filling percentage |
≥ 99% |
≥ 99% |
≥ 99% |
≥ 99% |
Power (kw) |
380V.50Hz 3.5KW |
380V.50Hz 3.5KW |
380V.50Hz 3.5KW |
380V.50Hz 7.5KW |
Vacuum |
27m3/h-0.02~-0.08Mpa |
27m3/h-0.02~-0.08Mpa |
52m3/h-0.02~-0.08Mpa |
27m3/h-0.02~-0.08Mpa |
Machine Dimensions |
1350x1020x1850 |
1350x1020x1850 |
1350x1020x1850 |
1220x960x2000 |
Weight(kg) |
850Kg |
850Kg |
850Kg |
1400Kg |
Noise Emission |
< 73dB(A) |
< 73dB(A) |
< 73dB(A) |
< 73dB(A) |
Company Information
Our Workshop
Our Services
We will design the machine up to your special request and assure every machine you choose from us is the right and best one.
Packaging & Shipping
FAQ
More questions, could you pls feel free to find us at any time!
