Help CenterDRB Network Audio Processor
Related Products
Specifications
DRB Series DSPDRB Series DSP Functions
• Delays: 5ms,10 ms,20 ms,50 ms,100 ms
• Routers:4 × 4,8 × 8,16 × 16
• Mixers:4 × 1, 4 × 2,4 × 4,8 × 1, 8 × 2, 8 × 4,8 × 8
• Dynamics: Leveler, Compressors, Limiters, Noise Gates, Expanders, Clipper
• Signal Generator: Sine, White noise
• Equalizes: Parametric Equalizes, Graphics Equalizes
• Filters: High-pass, Low-pass, Highpass Shelving, Lowpass shelving
• Crossovers: 2 way,3 way ,4 way
• Level Meters:1 way, 2 way, 4 way, 8 way
SPECIFICATIONS
• Frequency Response:20 Hz–20 KHz, ±0.2 dB
• THD plus Noise: <0.005% @ +4 dBu
• Dynamic Range: 103 dBA, 101 dB unweighted
• Maximum Input Level: +21 dBu, balanced
• Maximum Output Level: +21 dBu, balanced
• Input Gain Adjustment 0~66 dBu
• Input Impedance: 20 kΩ
• Output Impedance: 100 Ω, designed to drive a minimum load of 600 Ω
• Sampling rate:48KHz
• Digializing bit: 20 bit
• Processing 8 audio channels
• DSP Capability: 200 MIPS; 40-bit floating-point;
• 2 M bits on-chip, dual-ported SRAM; 4 M bits mask-programmable ROM
• Digital Interfaces:2 RJ45 CobraNet network ports; 1 RS-232 port; 1 GPIO port
• Analog Interfaces:
• DRB-8A: 8 channels output ( balanced )
• DRB-206A: 2 channels input ( balanced ) , 6 channels output ( balanced )
• Power Supply: 100–240 V AC, 50/60Hz
• Power Consumption: less than 30 W
• Dimensions (L×W×H) 430 x 291 x 44.5 mm without rack mounts
• Operating Environment Temperature Range: 5-40° C
• Operating Environment Humidity Range: 5-85%
