Specifications
single channel ecg1.Portable
2.Single channel
3.320X240 graphic LCD, 3.8 inch screen
4.Built-in rechargeable battery
(MSLPE06)high frequency and resolution portable single channel ecg( electrocardiogram)
Feature of single channel ecg
Single channel with measurement report
Built-in rechargeable Ni-MH battery
Chinese / English language
Simultaneous 12 leads
320X240 graphic LCD, 3.8 inch screen
Paper size: 50mmX20/30m
Built in RS232 interface (USB is optional)
8 Patients save/copy/communication
Specification of cheap single channel ecg
Items |
specification |
Lead |
standard 12 leads |
lead acquisition |
synchronously 12 leads |
Data acquisition |
18bit/1000Hz |
Record mode |
Manual mode; Auto 1; Auto 2; Auto 3 |
Filter |
AC, EMG,Drift Filter |
CMRR |
100dB(with AC filter) |
Input circuit |
Floating; Protection circuit against Defibrillator effect |
Input circuit current |
≤0.1μA |
Input Impedance |
≥2.5MΩ |
Patient current leakage |
<10μA |
Calibrating voltage |
1mV±2% |
Voltage Tolerance |
±500mV |
Time constant |
>3.2s |
Frequency response |
0.05 ~150Hz |
Noisy level |
≤15μVp-p |
Sensitivity valve |
≤20μV |
Inter-Channel Interference |
≤0.5mm |
Paper speed |
25,50mm/s(±3%) |
Sensitivity |
AUTO,2.5,5,10,20mm/mV |
Recording mode |
Thermal Array printing |
Paper specification |
50mmx20m,roll |
LCD display |
320x240 graphic LCD,display status&waveform. |
Safety classification |
IEC60601-1 class I, type CF |
Power supply |
AC : 110V/220V/85~265V,50/60Hz±1Hz;30VA |
DC :12V(1500mAh) rechargeable Ni-MH battery | |
Fuse |
AC extend T500mA/125V ¢5x20mm AC extend T250mA/250V ¢5x20mm AC extend T2.0A/250V ¢5x20mm |
Image/picture of single channel ecg
Welcome to medicalequipment-msl.en.china.cn. If you have any demand in single channel ecg(MSLPE06) . Please feel free to contact sophie(at)
We specialize in various Vet equipment, X-ray protective products, Automatic or fully-automatic hemotology analyzer, Incubators,Autoclaves dical equipment. Want to know more details about Medical equipment?Click here:medicalequipment-msl.en.china.cn
Through few years development. Because our products' better performance,high quality,favorable price and excellent pre-market after-sales services. We have became a professional supplier in Medical equipment. Our products are sold in Britain,American,Japan,Italy and South East Asia untry and well appreciated by their purchasers. Therefore,we have great confident that our products could meet your different requirements.
I hope we have more chance to cooperate with each other and both of us business is booming.Thank you for reading.
