rf anti-theft label

One-stop service for woven labels, printed label, hangtag, paper bags,custom woven labels,  rf anti-theft label ,save your time, save your money.

Frequency                    8.2MHz±328KHz

Amplitude                    Q≥67

Effective Volume           ≥2000cm³

Deactivation Strength    0.9A/m-1.5A/m

Operating Distance       1.4m-1.7m

Deactivation Distance    25cm-30cm ( 0.82'-0.98'

  eas rf security label 8.2MHz EAS label Roll Specifications

Labels Per Roll          1000 labels           2000 labels

Roll Length                42m ( 137.8')         84m ( 275.6' )

Diameter Inner Core    7.6cm ( 0.25' )       7.6cm ( 0.25' )

Roll Outer Diameter    14.8cm ( 0.9' )       18.8cm ( 0.49' )

Roll Weight                0.54kg ( 1.19lb )    1.07kg ( 2.36lb )

Case Weight              11.8kg ( 26.0lb )    11.0kg ( 24.3lb )

Rolls Per Case                  20                       10

Case Dimension    30.5cm×30.5cm×23.5cm  38.5cm×20cm×23.5cm

                                ( 1.00'×1.00'×0.77' )         ( 1.27'×0.66'×0.77' )

   eas rf security label  8.2MHz EAS label Dimension Specifications

Length                              40mm ( 1.31' )

Width                               40mm ( 1.31' )

Thicknessincluding liner     27μm

Thicknessexcluding liner    21μm

Label Spacing                   2mm ( 0.066' )

    eas rf security label 8.2MHz EAS label Material Specifications

Substrate               80g/m² glassing paper

Surface                  80g/m² thick reinforced paper

Inductor Side          Aluminum

Capacitor Side        Aluminum

Adhesive                Rubber-based, hot melt adhesive

     rf anti-theft label

                 rf anti-theft label

For any questions , you can contact, Joe, 86-18255923734 Skype:hangermarker
