Home > Consumer Electronics > Audio & Sets > Professional Audio > 850W 128dB 3 Way Coaxial Driver Digital Active Loudspeaker C-MARK TK315A

850W 128dB 3 Way Coaxial Driver Digital Active Loudspeaker C-MARK TK315A

850W 128dB 3 Way Coaxial Driver Digital Active Loudspeaker C-MARK TK315A thumbnail-1
850W 128dB 3 Way Coaxial Driver Digital Active Loudspeaker C-MARK TK315A thumbnail-2
850W 128dB 3 Way Coaxial Driver Digital Active Loudspeaker C-MARK TK315A photo-1
850W 128dB 3 Way Coaxial Driver Digital Active Loudspeaker C-MARK TK315A photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
C-MARK
Model Number:
TK315A
Contact Supplier Request Quote Chat Now
Shenzhen Bao Ye Heng Industrial Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Yantian/Shekou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name C-MARK
Model Number TK315A

Specifications

performs super bass effect
3 way coaxial driver drives HF,LF and Sub
Pre-amp components
3-channel Class D amplifier circuits

Brief Introduction
TK315A digital active loudspeaker performs super bass effect, it consists of a coaxial driver that drives all HF, LF and Sub at one single point. This loudspeaker features high efficiency, high sound output, refined sound quality, perfect protection functions and good EMC characteristics. And it adapts power supply voltage from AC 100V to 240V 50/60Hz, suitable for universal power. TK315A is designed for venues like Karaoke hall, auditoriums, meeting rooms and multifunctional halls for large SPL.

Main Features
1. Adopted 3 way coaxial driver, using unique one-magnet-three-loop technology. The diagrams of HF, LF and Sub make the sound in the same axis point, so that all frequency sounds synchronously, with no time difference. With clear HF and LF, sub bass deep, strong and vigorous, it provides even sound field distribution, both horizontal and vertical dispersion angle are 120 °
2. Using PFC technology switching power supply components, adopts wide voltage range AC 100V-240V 50/60Hz global power supply.
3. Using independent 3-channel Class D amplifier circuits, high energy conversion efficiency, low-carbon and environmental friendly.
4. Pre-amplifier components using three way crossover circuits, with independent gain setting for HF, MF, LF.
5.  Plug and Play, convenient to use, clear instructions, can be installed and operated easily even by non-professionals.
6.  Efficient and safe dynamic compression function on power output and temperature protection circuit, free users from worries.
7.  Suitable for a wide range of applications: commercial, night club, entertainment, schools, military and so on.

Technical Parameters
Model No.
TK315A
HF Power (8Ω):
100W RMS
MF Power (8Ω):
250W RMS
LF Power(4Ω):
500W RMS
Power in total:
850W RMS
Components:
LMH151244ND (15” + 12” + 1.75”) neodymium
Frequency response:
40Hz-18KHz
Crossover point:
LP 200Hz HP 3KHz
Max power:
1700W
Sensitivity:
99dB(1W/1m)
THD:
< 0.1%
SPL:
128dB
Slope:
40dB/10
Power supply:
100-240V ~50/60Hz AC
