C-Mark Large Outdoor Active Line Array LND32A

                                 C-Mark Large outdoor active line array LND32A

  C-Mark LND32A active line array loudspeaker is powered by digital power amplifier, features high efficiency, best sound, safe protection, incredible compatibility of electromagnetism and open choices of  110VAC and 220VAC power supply. Suspension of the line array allows up to 9 degree of curvature adjustment, covering area thus wider. Tight, light and bright installation.

Features:

1. Plug & play, user-friendly, clear indication, easy manipulating for nonprofessionals.

2. LND32A is light weighted but very powerful by 12"woofer and 3"tweeter.

3. Built-in digital power amplifier features best sound, high effeciency and high reliability.

4. Complete protection from short circuit, over surge current, over heat, over voltage, power limiting, over temperature frees users from worry of malfunction.

5. Suitable for many applications like commercial, company, entertainment, school and army etc.

Specifictions:

Components: 2 x 12"(MF1275AND  x 2) neodium-magnet LF driver

                        1 x 3" (Hi75TiND  x 1) neodium-magnet HF driver

High Frequency Power: 300W RMS

Low Frequency Power: 1000W RMS

Total Power: 1300W RMS

Max Power: 1600W RMS

Input Power: Lo 600w/ 4Ω

                      Hi  80w/ 8Ω

Input Impedance: 22KΩ

Frequency Response: 50Hz - 18KHz

Sensitivity:128dB(1m/1w)

N.W. : 44.5kg

G.W. : 153kg

Net Dimension: 1160(L)X890(W)X720(H) mm

Vertical: depending on curvature

Vertical angle adjustable: 0-9 degree

Packing:

N.W. 44.5kg

By flight case

G.W. 153kg (2 pcs per flight case)

Dimension: 1160(L) x 890(W) x 740(H) mm

Cubage: 0.76cbm

Contact person: Lily Ke

Mobile: 0086-13922799670

Tel: 0086-0755-83927649

 Outdoor   Projects:
