MF Series Agitator Hydraulic Motor
- 100 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
Type: | Other, Hydraulic Motors, Piston motor | Brand Name: | Highland | Place of Origin: | Shandong, China |
Packaging Details
in wooden case
Product Description
Agitator Hydraulic Motor
1. Bent axis design with fixed displacement
2. Completely interchangeable with original
3. For use as either pump or motor in hydrostatic drivers,in open of closed circuit
4. High performance rotary group with well-proven spherical control area with the advantages;self-centering low peripheral
speed ,high efficiency
5. Robust rolling bearings endure long service life
6. Drive shaft capable of adopting radial loading
7. Size:A2F6, A2F10, A2F12, A2F23, A2F28, A2F45, A2F55, A2F63, A2F80,A2F107, A2F125, A2F160, A2F200, A2F250, A2F355,
A2F500
Technical Specifications
Size | 6 | 10 | 12 | 23 | 28 | 45 | 55 | 63 | 80 | 107 | 125 | 160 | 200 | 250 | 355 | 500 |
Speed r/min | 3000 | 3000 | 3000 | 2500 | 2500 | 2500 | 2500 | 2500 | 2240 | 2000 | 2000 | 1750 | 1750 | 1500 | 1200 | 1200 |
Rated pressure Mpa | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 31.5 | 31.5 | 31.5 | 31.5 |
Power Kw | 10.3 | 17.2 | 20.5 | 32.9 | 40 | 65 | 79 | 90 | 103 | 123 | 143 | 160 | 181 | 193 | 219 | 309 |
n=1450 r/min p=35Mpa(31.5Mpa) Power Kw | 5 | 8.2 | 10 | 19 | 24 | 37 | 45.6 | 52.2 | 66.3 | 89 | 104 | 132 | 150 | 187 | -- | -- |
Torque N.m | 33.4 | 55.7 | 66.8 | 127 | 155 | 250 | 306 | 350 | 445 | 595 | 695 | 890 | 1001 | 1252 | 1778 | 2504 |
Weight Kg | 5 | 5 | 5 | 12 | 12 | 23 | 23 | 33 | 33 | 44 | 44 | 63 | 88 | 88 | 138 | 185 |
Company Profile
Profile
Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing.
Hydraulic Pump
Hydraulic Comprehensive Test Bench
Digital Hydraulic Test Bench
MYHT Portable Hydraulic Tester
Hydraulic Pump Parts
Service: On-site technical advisory for Hydraulic System
Maintenance: Hydraulic Pump or Motor imported or made in China
Jinan High Land Hydraulic Pump Co.,Ltd.
Address:N0.26, Beiyuan Street, Licheng District, Jinan
Tel: 0086-0531-88796130 88770136
Fax: 0086-0531-88796120
Technical Support: 13805406089
Post Code: 250100
Hydraulic Digital Test Bench
Maintenance and test equipment for testing Hydraulic Pump, Motor
Parameters:
Flow: 300-500L/Min
Pressure:35Mpa
Power: 75-250KW
Motive Power: Hydraulic Electromotor, Frequency Conversion Electromotor, Diesel Engine Drive
Portable Hydraulic Tester
MYHT Portable Hydraulic Tester is applicable for testing flow, pressure, temperature of hydraulic system of construction equipment. It widely absorbs advanced technical experience of international peers and has filled the blank of this field in China.
Potent No.: ZL 2005 2 0080054.X
Parameters:
Flow: 200---800L/Min.
Precision:1%
Pressure: 420bar
Temperature:150
Weight: 6.2-10.5kg
Product: Hydraulic Pump, Hydraulic Comprehensive Test Bench, Digital Hydraulic Test Bench, Portable Hydraulic Tester
Service: on-site technical advisory for hydraulic system, system reform, parts test
Maintenance: Hydraulic Piston Pump, Piston Motor, Valve, Sauer Pv20,90 series RexrothA10V, A4V, A11series, Kawasaki K3V, NV series, Komatsu, CAT
