Specifications
CM-1325S Headstone CNC Engraving Machine1.Heavy-duty Lath
2. Hiwin Linear Guide Rail
3.X,Y Are Both Gear And Pinion
CM-1325S Headstone CNC Engraving Machine
1.Total heavy workframe which is necessary for stone engraving.
2.The bed height is lower for put on the heavy stone easily.
3.Tank wall is stainless steel in case of being rusty while touch water.
4.3.0kw-8.0kw spindle is optional.
Applicable industries:
Tombstone,menument,grave stone,headstone,etc.
Applicable materials:
Marble, Granite and other stone.
Description |
Parameter |
X,Y Working Area |
1300*2500mm |
Z Working Area |
140mm |
Resolution |
+0.01mm |
Lathe Structure |
Welded steel structure |
X,Y Structure |
Gear Rack transmission |
Z Structure |
Germany rolling ball screw, Hiwin square guide rail |
Max. Idling Speed |
25m/min |
Spindle |
3.0KW/4.5KW/6.0KW/8.0KW |
Spindle Rotate Speed |
0-24000r/min, variable speed |
Inverter |
Delta |
Working Voltage |
AC380V/50Hz |
Working Mode |
Stepper |
Driver |
YAKO |
Command |
G code,HPGL,U00,mmg,plt |
Operating System |
DSP with USB interface/Weihong |
Diameter of cutter |
φ3.175-φ12.7mm |
Cooling Mode |
Water-cooling |
Work-holding |
By Clamp |
Water Tank |
Yes |
Net Weight |
2000KG |
Gross Weight |
2100KG |
