Specifications
CM-1325 CNC Stone Router Multi Spindle Engraver Machine1.DSP System
2.Hiwin Square Guide Way
3.Water Tank
4.Yako Driver
CM-1325 CNC Stone Router Multi Spindle Engraver Machine
Standard Features:
- Whole machine is welded with steel tube, the stability is excellent, not easy to be deformed
- The machine adopts gantry movement, it can process any kinds of materials freely.
- Three axes adopt Taiwan Hiwin high precision square guide rails; X and Y axes adopt rack and pinion transmission, fast working, high efficiency and low cost. Z axis adopts Germany-made ball screw,with high precision and longevity.
- Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.
- Has the function of re-carving after break point and power failure.
- Has the function of forecasting process time.
- Adopting advanced DSP system with USB connection, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources.
- Perfect oil-inject system makes maintenance much easier.
- Has water tank. It will collect the cooled water which is used for cooling the cutting tool.
- Adopting water cooling system, it can provide good cooling effect when carving flinty materials.
Applicable Industries:
Wood processing: processing of various furniture such as door, window, cabinet, craft wood door, screen and so on.
Advertisement: engraving and cutting various labels and number plate.
Art craft: engraving characters of any languages and graphics on gifts and souvenirs.
Applicable Materials:
Wood, aluminum board, plastic, density board, MDF board, wave board, PVC, acrylic,crystal, light marble and other nonmetal materials and light metal materials.
Description |
Parameter |
X,Y Working Area |
1300*2500mm |
Z Working Area |
300mm |
Resolution |
0.05mm |
Lathe Structure |
Welded steel structure |
X,Y Structure |
Rack and pinion transmission |
Z Structure |
Germanyrolling ball screw, Hiwin square guide rail |
Max. Idling Speed |
35m/min |
Spindle |
4.5KW |
Spindle Rotate Speed |
0-24000r/min, variable speed |
Inverter |
Fuling |
Working Voltage |
AC380V/50Hz,Three Phase |
Working Mode |
Sub-division Stepper Motor |
Driver |
YAKO2811 |
Command |
G code,HPGL,U00,mmg,plt |
Operating System |
DSP with USB interface |
Diameter of cutter |
φ3.175-φ12.7mm |
Cooling Mode |
Water-cooling |
Work-holding |
By Clamp |
Net Weight |
2000KGS |
Gross Weight |
2100KGS |
