Home > Lights & Lighting > LED Interior Lighting > LED Down Light > 20W 8inch SMD LED Downlight 20W Recessed IP44 LED Downlight

20W 8inch SMD LED Downlight 20W Recessed IP44 LED Downlight

Name: 20W 8inch SMD LED Downlight 20W Recessed IP44 LED Downlight
Brand: Real Green
SKU: 114926237

20W 8inch SMD LED Downlight 20W Recessed IP44 LED Downlight thumbnail-1

20W 8inch SMD LED Downlight 20W Recessed IP44 LED Downlight photo-1

US$ 11.21 - 11.21 MOQ: 50 Units

Key Specifications

Get Latest Price

LED Light Source:

SMD 5730

Warranty(Years):

Input Voltage(V):

85-265V

Contact Supplier Request Quote Chat Now

Jiangmen Real Green Lighting Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Jiangmen Port Shenzhen Port Guangzhou Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source SMD 5730

Warranty(Years) 2

Input Voltage(V) 85-265V

Lamp Power(W) 20

Lamp Luminous Flux(lm) 1460

Lamp Luminous Efficiency(lm/w) 73

Color Temperature(CCT) Other, 3000K-6500K

Working Temperature(℃) -30, 70

Working Lifetime(Hour) 500000

Lamp Body Material Aluminum Alloy

IP Rating IP44

Certification CE

Model Number RG-SMDTD020

Place of Origin Guangdong, China

Brand Name Real Green

The LED Downlight series products is formed by lower power LEDs and Aluminum Alloy,the shell design has combined the LED luminous angle.

To acheive reflection and high heat dissipation transmittance,we quality bonding LED chips and lamp base.

It has the advantages if energy-saving,environment conservative,long serice life,suitable for office,meeting room etc,.

Product Description

Features of Real Green LED SMD Downlight:

Newly design fit most 8" recessed cans
Long life LEDs up to 50,000 hours at 70% lumen maintenance
Includes medium connector
110V-240V Working Voltage available
Save 75% compared to incandescent sources
No tools required for installation
Tested in accordance with CE / RoHS / UL / SASO

Product Parameters:

BASIC PARAMETERS
Brand Name:	Real Green	Item No.:	RG-SMDTD020
Power	20W	LED Type:	SMD Lighting
Emitting Color:	Warm White / Cool White	Material:	AluminumAlloy+PMMA
Shape Size:	Ø165 mm	Beam Angel(°):	120°
LM/W:	73LM/W	IP Rating:	IP44
Lumen :	1460LM	Lifespan:	50,000 Hr
SDCM Range:	<7.5	Color Temp.:	3000K
ELECTRICAL PARAMETERS
Input Voltage(V):	AC220V	Working Temperature(℃):	-30 ℃- 70 ℃
Power Factor(PF):	≥0.97	Power Factor(PF):	≥ 0.427
Color Rendering Index(CRI):	>85
PACKING PARAMETERS
Packing Size(Carton):	19080185mm
Packing Details:	Cartion box with plastic bag

LED Driver

No flicking
Down to 5% with standard incandescent or low voltage drivers.
High efficiency driver with a power factor >.90 with input power of 220V, 60Hz
Adapted imported quality IC raw material

LED Down Light 6500K 100V-265V:

1. Using SMD5730 or as customer's request.

2. Using Isolated driver - more safe
3. Using good heat dissipation heat sink, extending life of LEDS.
4. lower light attenuation to 13%-14% in 2 year
5.led source,led downlight save more than 80% compare to incandescent lamp, save more than 60% compared to fluorescent light
nstant current, low power consumption, electro optic power near 100%

Why you choose our LED SMD Downlight?

1. Use die-casting aluminum alloy as the material of main-body.
2. Use high transparent PMMA as lens, high pure reflector makes sure more light coming out
3. Fashionable &novel looking design, ultra thin aluminum body for easy operating.
4. Excellent heat dissipation performance.
5. Isolated driver, ensure the long life span.
6. Energy-saving and high efficient LED driver.

Application Case:

Led downlight Application:

1. Recessed lighting , shelf lighting, ceiling/wall cover
2. Cabinet and under counter lighting, office ect.
3. Back lighting, step lighting, light boxes
4. Merchandising, exhibition stands, and panels

5.Commercial application

Notices:
1. Open the packaging, check the products carefully, and take them gently.
2. The wire must be passed 3C certification of three core cable, To reduce the risk of fire hazard.
3. Wire copper is not exposed outside of the power terminal holes, To avoid a short circuit or get electrocuted.
4. Installation and removal products, please disconnect the light's power to avoid the risk of electric shock.

Acutions: All of this install instruction is for conference, please install the down light in professional instruction.

Packaging & Shipping

With strong carton packing,and also customized.

Packing size: 195*80*185 mm

We offer various shipping way for your conference,like UPS/COD/EMS/Fedex etc,.

5-10 days will be sent to the destination

Fedex/UPS/DHL/EMS we accept.

The shipping charge according to the weight of products.
