Portable Concrete Mixer Pump Tester
- Qingdao
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | High Land | |
| Model Number | MYHT-1-7 |
wooden case
Product Description
portable concrete mixer pump tester
Application Range The MYHT Digital Portable Hydraulic Tester is an all-in-one unit designed to test the performance of hydraulic pumps,motors,valves and hydrostatic transmissions.
The easy-to-use design allows the operator to just switch on and test,without cornptex setup or speciat training.
The MYHT is the ideai tooi for pinpointing hydraulic system faults,reducing downtime,and helping in preventative maintenance.
Simple operation includes a toggle switch to display either flow or temperature readings and a built-in loading valve is specifically designed to enable the operator to simulate the maximum working pressure safely during normal machine operation.
Features
1.ACCURATE measurement of flow,pressure,peak pressure and temperature.
2.SAFE to use in both directions of flow.
Internal oil by-pass protects muitimeter and operato against OVerpressure.
3.Bi-DIRECTIONAL for unrestricted connection and simplified testing.
4.FAST checks on pumps,motors,valves,cylinders,hydrostatic transmissions.
5.EASY to operate controls.Connect Into the hydraulic system and simply“Switch on”.
6.PORTABLE AND LIGHTWEIGHT with the case for easier viewing and cleaning.
7.RECHARGEABLE POWER:lithium battedes 12v.
Technical Specifications :
model | ||||
model | Max flow (LPM) | Max pressure (Bar) | Dimension (mm) | Weight |
MYHT-1-2 | 200 | 420 | 295x265x210 | 6.1 |
MYHT-1-4 | 400 | 420 | 295x265x210 | 8.8 |
MYHT-1-5 | 500 | 420 | 295x265x210 | 10.2 |
|
|
| ||
MYHT-1-7 | 700 | 420 | 310x285x261 | 14 |
Company Profile
Profile Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing. Hydraulic Pump Hydraulic Comprehensive Test Bench Digital Hydraulic Test Bench MYHT Portable Hydraulic Tester Hydraulic Pump Parts Service: On-site technical advisory for Hydraulic System Maintenance: Hydraulic Pump or Motor imported or made in China Jinan High Land Hydraulic Pump Co.,Ltd. Address:N0.26, Beiyuan Street, Licheng District, Jinan Tel: 0086-0531-88796130 88770136 Fax: 0086-0531-88796120 Technical Support: 13805406089 Post Code: 250100 Hydraulic Digital Test Bench Maintenance and test equipment for testing Hydraulic Pump, Motor Parameters: Flow: 300-500L/Min Pressure:35Mpa Power: 75-250KW Motive Power: Hydraulic Electromotor, Frequency Conversion Electromotor, Diesel Engine Drive Portable Hydraulic Tester MYHT Portable Hydraulic Tester is applicable for testing flow, pressure, temperature of hydraulic system of construction equipment. It widely absorbs advanced technical experience of international peers and has filled the blank of this field in China. Potent No.: ZL 2005 2 0080054.X Parameters: Flow: 200---800L/Min. Precision:1% Pressure: 420bar Temperature:150 Weight: 6.2-10.5kg Product: Hydraulic Pump, Hydraulic Comprehensive Test Bench, Digital Hydraulic Test Bench, Portable Hydraulic Tester Service: on-site technical advisory for hydraulic system, system reform, parts test Maintenance: Hydraulic Piston Pump, Piston Motor, Valve, Sauer Pv20,90 series RexrothA10V, A4V, A11series, Kawasaki K3V, NV series, Komatsu, CAT
