Hydraulic Speed Reducer for Concrete Mixers

Name: Hydraulic Speed Reducer for Concrete Mixers
Brand: Highland
SKU: 114919597

US$ 1,000 - 3,000 MOQ: 1 Set

Key Specifications

Gearing Arrangement:

Spur

Output Torque:

25000N.m

Input Speed:

800r/min

Ji'nan High Land Hydraulic Pump Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Gearing Arrangement Spur

Output Torque 25000N.m

Input Speed 800r/min

Place of Origin Shandong, China

Model Number HLMC-55/70

Brand Name Highland

Specifications

Truck Mixer Gearbox and Speed Reducer
1.Max.input speed 2500rpm
2.output torque 42000Nm-72000Nm

3-14 cubic meter Truck Mixer Gearbox

concrete mixers gear units use the European technology, the product follows modular, the maximized design idea,

to ensure the product's low noise, low vibration and high load, long life,

which can effectively ensure overall performance, the gear use special modification techniques with carburizing quenching by the grinding process,

the products use to big power cement mixer truck, and may satisfy the concrete mixing drum.

Widely applied to the injection molding machine / die

casting machine / hydraulic press / hydraulic / ship

machinery / construction machinery concrete pump

truck / mixer truck / construction machinery / rotary

drilling rig / Tractor / loader / roller / Paver / lifting

crane machinery / shoe machine/ coal Mining construction

basic parameter
Model	HLMC-55	HLMC-70	HLMC-80
Supporting mixing tank capacity	8~9m³	10m³	12m³
Maximum output torque	56000Nm	62000Nm	74000Nm
reduction ratio	134:1	136:1	145:1
Installation Max Angle	15/12	11	10
Weight	333KG	342KG	349KG
