Home > Products > Hydraulic Test Equipment > Hydraulic Pump and Motor Testing Table
Hydraulic Pump and Motor Testing Table
- QingDao
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Highland | |
| Model Number | YST 500KW | Power | Hydraulic | |
| Usage | Vibration Testing Machine |
wooden case or as customer required.
Product Description
Specifications
1. got the country patent,acquired ISO9001:20082.special manufacturer.
3. Advanced technology and time guarantee.
We are Jinan High Land Hydraulic Pump Co;ltd , the professional designer, manufacturer and repairman of hydraulic pumps ,motors and test instrument and hdyraulic test bench.
1. got the country patent: and acquired ISO 9001:2000; ISO9001:2008
2. Advanced technology and time guarantee.
The portable high pressure pump tester is used for checking and surveying hydraulic systems discharge, pressure and temperature, is the initiation in china, and has gotten the country patent.
1. Portable Testing gauge tech data:
PRODUCT | TYPE | PARAMETER | ||||||
FLOW | PRECESSION | PRESSURE | TEMPERATUER | WEIGHT | SIZE | |||
Portable hydraulic tester | MYHT-1-2 | 200L/min | 1% | 420bar | 150 | 6.1kg | 295×265×210(mm) | |
Portable hydraulic tester | MYHT-1-4 | 400L/min | 1% | 420bar | 150 | 8.8kg | 295×265×210(mm) | |
Portable hydraulic tester | MYHT-1-5 | 500L/MIN | 1% | 420bar | 150 | 10.2kg | 295×265×210(mm) | |
Portable hydraulic tester | MYHT-1-7 | 700L/MIN | 1% | 420bar | 150 | 10.2kg | 295×265×210(mm) | |
Advantage:
1. Accurate measurement of flow, pressure, peak pressure and temperature.
Safe to use in both direction of flow.
2. Bi-directional for unrestricted connection and simplified testing.
3. Fast checks on pumps, motors, valves, cylinders, hydrostatic transmissions.
4. Easy to operate controls.
5. Flow rate: 380L/Min Pressure: 35mpa
Price: | Get Latest Our Best Price |
Minimum Order Quantity: | 1 Set |
Port: | QingDao ,Port China |
Packaging Details: | Wooden cases or as customer required. |
Delivery Time: | Within 30 days after the order confirmed. |
Payment Terms: | T/T |
Supply Ability: | 40/Sets per year |
Any question or needs, please feel free to contact us.
Waiting for your earlier reply.
Company Profile
Profile Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing. Hydraulic Pump Hydraulic Comprehensive Test Bench Digital Hydraulic Test Bench MYHT Portable Hydraulic Tester Hydraulic Pump Parts Service: On-site technical advisory for Hydraulic System Maintenance: Hydraulic Pump or Motor imported or made in China Jinan High Land Hydraulic Pump Co.,Ltd. Address:N0.26, Beiyuan Street, Licheng District, Jinan Tel: 0086-0531-88796130 88770136 Fax: 0086-0531-88796120 Technical Support: 13805406089 Post Code: 250100 Hydraulic Digital Test Bench Maintenance and test equipment for testing Hydraulic Pump, Motor Parameters: Flow: 300-500L/Min Pressure:35Mpa Power: 75-250KW Motive Power: Hydraulic Electromotor, Frequency Conversion Electromotor, Diesel Engine Drive Portable Hydraulic Tester MYHT Portable Hydraulic Tester is applicable for testing flow, pressure, temperature of hydraulic system of construction equipment. It widely absorbs advanced technical experience of international peers and has filled the blank of this field in China. Potent No.: ZL 2005 2 0080054.X Parameters: Flow: 200---800L/Min. Precision:1% Pressure: 420bar Temperature:150 Weight: 6.2-10.5kg Product: Hydraulic Pump, Hydraulic Comprehensive Test Bench, Digital Hydraulic Test Bench, Portable Hydraulic Tester Service: on-site technical advisory for hydraulic system, system reform, parts test Maintenance: Hydraulic Piston Pump, Piston Motor, Valve, Sauer Pv20,90 series RexrothA10V, A4V, A11series, Kawasaki K3V, NV series, Komatsu, CAT
