China best Asphalt Rubber Plant,10-15Ton
Application
GYXL3515 asphalt rubber plant is a type of special equipment to produce asphalt rubber. This equipment is mainly consisted of rubber powder conveying device, heating system, fast heating-up device of base asphalt, asphalt metering pumping system, high speed shearing and mixing device, mixtures reaction device and automatic control system.
Main Technical Parameters
ITEM |
PARAMETER |
UNIT |
|
Model |
GYXL3515 |
|
|
Productivity |
10-15 |
t/h |
|
Total Installed Power |
120 |
Kw |
|
Fast Heating-up Device |
Heating capacity |
125×104 |
kcal |
Heat exchange area |
2×32 |
M2 |
|
Heat exchange coefficient |
50 (20t/h) |
℃ |
|
Measuring Precision |
≤0.5 |
% |
|
Rubber Powder Charging System |
Measuring precision |
≤0.5 |
% |
Capacity of helical feeder |
10 |
m3/h |
|
Base Asphalt System |
Max. flow rate |
1300 |
L/min |
Rubber Powder & Asphalt Mixer |
Mixer rotary speed |
2900 |
rpm |
Mixer power |
11 |
kw |
|
Reaction Kettle |
Heating power of burner |
2×20×104 |
kcal |
Kettle capacity |
2×17.5 |
m3 |
|
Max. capacity of asphalt rubber pump |
40 |
m3/h |
|
Mixing speed |
198 |
rpm |
|
Mixing power |
2×11 |
kw |
|
Advantages
1) GYX3515 asphalt rubber plant is independently developed by our company with our own intellectual property rights and several national patents, which is away from property right dispute.
2) Fast heating-up device of large area speeds up the heat exchange which heating the asphalt for 45-65 degrees at the flow rate of 20t/h to avoid asphalt aging and make full use of heat and reduce production costs.
3) Flow meter is applied to measure the asphalt flow accurately. Rubber metering device measures the rubber powder amount accurately to keep the precision less than 0.1%.
4) Patented high-speed rotary cutting technology by ourselves, which realizes rotary speed of 2900rpm only at home with high cutting efficiency, makes for the mixing process and storage of rubber modified asphalt and scatters the aggregates.
5) Horizontal shaft mixer is used to distribute the rubber powder in the binders to stabilize the binders’ technical data in favor of mixing rubber powder and asphalt well.
6) Specially-made nozzle of imported burner of large power makes the flame angle more appropriate, which is energy-saving and noise-canceling. Fast heating speed and sound heat-insulating property benefit the process reaction of rubber modified asphalt.
7) Safe and fast HTF heating system with high heating efficiency of 10-15℃/ h shortens warm-up and standby time to reduce auxiliary production time.
8) Sound thermal insulation layer keeps static thermal insulation index at less than 12℃/8 hours.
9) Stainless steel board packing is corrosion resistant and durable. Iron boards with anti-corrosion treatment inside at low costs are generally adopted by other manufacturers at home.
As an experienced road maintenance machine manufacturer in China, we supply automatic
asphalt distributor, synchronous chip sealer, fiber chip sealer, asphalt emulsion plant,
intelligent asphalt rubber plant, intelligent micro surfacing paver (slurry paver), snow removal machines,
municipal road management equipment and more to customers all over the world.
With the efforts of our excellent and unceasing technical R&D team, we obtain 108 national
patents and 12 TOP products of China, 3 TOP products of the world. Our machine also support
the outstanding projects like the most famous street of China Chang An Avenue major repair
forthe 60th anniversary of the founding of PRC, 2010 Shanghai World Expo Park, Motorway of Shanghai Pudong International Airport, airstrip of Shanghai Hongqiao International Airport,
Motorway of Guangzhou Baiyun International Airport for 2010 Asian Games, etc.
Workshop
Certifications
Sales network
We obsess professional and experienced technical service personnel,provide the users with low-cost and high-quality products and rapid-response services after sales.
