Qualified Micro surfacing paver,slurry paver
Application
HGY5161GLQ automatic asphalt distributor is a kind of intelligent hi-tech product specialized in spraying emulsified asphalt, diluted asphalt, hot asphalt, heavy-duty asphalt and high viscous modified asphalt and so on.
This product has widely applied in highway construction and road maintenance. It could be used to deal with upper and lower seal coat, prime layer, waterproof layer, adhesive layer, asphalt surfacing, asphalt penetration surface, fog seal layer and so on. It also could be used to transport liquid asphalt and other heavy oil.
Main Technical Parameters
Spray width: |
200—6000mm |
Spray volume: |
0.2—3.0 kg/m2 |
Asphalt tank volume: |
8000L |
Asphalt heating mode: |
Imported diesel oil burner (calorific value 10×104kCal/h) |
Spray media: |
hot (modified) asphalt, diluted asphalt, emulsified asphalt, etc. |
Spray precision: |
±1.5% |
Total weight: |
16000kg |
Overall dimensions: |
L×W×H=8830×2496×3420(mm) |
Advantages
1.This equipment reduces the construction labor intensity, budgets and human resources, improves the work efficiency and work quality.
2.The machine is working very stable. The asphalt spray width can be adjusted flexibly.
3. Good anticorrosive and durable insulation layer makes sure the temperature drop no more than 1oC/h.
4. Nozzles of high precision ensure the spray consistency and good results.
5.Humanized design of control system could not only control remotely, but also operate on site, which makes the operation more convenient.
6.With much engineering construction experience, we improve the equipment to make it more reliable in performance and more convenient in operation and maintenance.
As an experienced road maintenance machine manufacturer in China, we supply automatic
asphalt distributor, synchronous chip sealer, fiber chip sealer, asphalt emulsion plant,
intelligent asphalt rubber plant, intelligent micro surfacing paver (slurry paver), snow removal machines,
municipal road management equipment and more to customers all over the world.
Workshop
Products
Projects and Certificates
With the efforts of our excellent and unceasing technical R&D team, we obtain 108 national
patents and 12 TOP products of China, 3 TOP products of the world. Our machine also support
the outstanding projects like the most famous street of China Chang An Avenue major repair
forthe 60th anniversary of the founding of PRC, 2010 Shanghai World Expo Park, Motorway of Shanghai Pudong International Airport, airstrip of Shanghai Hongqiao International Airport,
Motorway of Guangzhou Baiyun International Airport for 2010 Asian Games, etc.
We obsess professional and experienced technical service personnel,provide the users with low-cost and high-quality products and rapid-response services after sales.
