SRBX23-4 copper and aluminum distribution coil winding machine
Descriptions of CNC Automatic winding machine
Spindle number |
4 |
Wire size range |
0.04-0.45mm |
Loop diameter |
90mm |
The max wire spacing |
9.99mm |
Winder width |
100mm |
Max speed |
0-6000 turns/min |
Spindle pitch |
165mm |
Input power |
220V 50HZ/60HZ |
spindle motor |
AC1/2three phase motor+1HP transducer |
winder motor |
stepping motor |
Machine size |
900×460×600mm |
Package size |
980×670×680mm |
net weight |
85kg |
gross weight |
100kg |
Application range:
EE transformer,EI transformer,Stepping motor,Relay,coil class,auto ABS,
Switch power transformer and special products.
1. Q: What is the power supply of the machine?
A: The standard power supply in china is 220v 50Hz. We also can customized accordingly.
2. Q: What information should the customer provide to get an accurate quotation from us?
A: The customer should provide the related technical requirements, drawings, pictures, etc .
3. Q: What is the payment term
A: The payment term is 100% T/T before shipment.
4. Q: What is the delivery time?
A: Normally the delivery time of the machine is 4-5 working days after receive payment.
5. Q: What is the warranty period of the machine?
A: The warranty period is one year.
6. Q: How to contact us?
A:Web:
| Europe: | Germany,Czech Republic, |
| Russia, | |
| UK, France | |
| Bulgaria, | |
| Italy | |
| North America: | USA, Canada, Mexico |
| South America: | South America |
| Australia | Australia |
| Asia : | China, |
| Singapore , Malaysia , Indonesia ,Vietnam, Tailand,Myanmar, | |
| Bengal,India, Pakistan, | |
| Turkey,Iran,Syria, ,UAE | |
| Africa: | Egypt, Tunis, ,Algeria, Dominica, |
|
South Africa |
