ITC TS-211 5.1 Channel Built-in DSP Digital Sound Processor

Model

TS-211

Input channel jacks

3 front 1 /4" phono inputs, 2 pairs of RCA inputs , 1 pair of female XLR, 1 against 3 RCA Video Inputs, 3 groups with 5 channel mic input.

Output channel jacks

Kp23+: 3.1 channel male-output; Kp24: 4 channel male-output: KP25+: 5.1 channel male output.

Input impedance

Balanced: 20KΩ.

Output impedance

Balanced: 100Ω.

PC port

One USB Com Port on front panel

CMRR

>70dB(1KHz)

Input range

≤+25db

Frequency response

20Hz-20KHz(-0.5db)

S/N R

>110db

THD

<0.01% OUTPUT=0db/1KHz

Crosstalk of channels

>80db(1KHz)

Functions of input channels

Input mute

Each channel has independent mute control.

Input delay

Input polarity

Each channel has independent delay control;  range: 0—30ms, step-over @1ms.

Same phase (+/+) or reversed phase (+/-).

Input EQ

Music and mic inputs come with 9 bands of individuals parametric EQ. Central frequency point: 20Hz to 20KHz, Bandwidth:  0.01oct to 3oct, Step-over is 0.01oct.

Input gain

Default frequency: EQ140Hz, EQ280Hz, EQ3160Hz, EQ4317Hz, EQ5632Hz, EQ6126Hz, EQ72515Hz, EQ85018Hz, EQ910KHz.  Also, High-cut and Low Cut Filter is added.

Both music and mic have independent gain control from 0% -100%.

Limiter

Both music and mic have independent limiter control, -30db to +20dB, stepover,0.1db.

Feedback

Mic comes with 4-levels anti-feedback function

Functions of output channels

Output mute

Each channel has independent mute control.

Output gain

Each channel has independent gain control. Adjustable range 0%-100%, step-over 1% 0.5dB.

Output delay

Each channel has independent delay control,  range: 0—1000ms,step-over 21us@<10ms; step-over 84us@10-20ms; step-over:0.5ms@>20ms.

Output polarity

Same phase (+/+) or reversed phase (+/-).

Crossover

Each channel can set up LPF and HPF independently, with adjustable parameters: Filter types: Linkwitz-Riley/Besse/Butterworth.Frequency turning point: 20Hz-20KHz,

239 total frequency points, decay of slope: 12db/oct, 18db/oct, 24db/oct, 48dB/oct.

Limiter

Each channel can set up limiters independently (all with adjustable parameters): Threshold value: -20db to +20db. Step-over: 0.5dBu@starting time: 0.3ms-100ms,

step-over<1ms @0.1ms, Step-over>1ms@1ms.

Output EQ

Each output channel can be set up with 7 bands of individual EQ. PEQ and GEQ modes are both present . Under PEQ, the adjustable parameters are :LO-EQ1 (bass

boost or low cut), H1-EQ15 (high boost or high damp) are the frequency points, all adjustable. Slope options are 12dB/oct, 24dB/oct, 36dB/oct and 48Db/oct. Others

option are: 13-bands of parametric EQ. There are total of 239 frequency points. Bandwidth: 0.01oct-3oct, step-over is 0.05oct. Gain: -40db to +20db, step-ver is

0.1dB. When set as GEQ, the functions are the same as when set as PEQ.

Effects processor

1M of Memory, includes 3 bands of parametric EQ.

Processor

96KHz sampling frequency, 32-bit floating-point DSP.

Display

Resolution of 144x32 character LCD and 6-segment LED display for accurate digital input and output level meter, mute and edit status

Power

≤25W.

Power supply

AC110V/220V    50/60Hz.

Product dimension(W×D×H)

482×200×44mm.

Net  weight

3.75kg.

Shipping dimension(W×D×H)

1 piece: 562x294x98mm/0.0162m3   6 pieces: 576X308X612mm/0.1123m3

Gross weight

1 piece: 4.7(kg)   1 piece: 4.7(kg)
