ITC T-6600 8*16 Matrix Internal MP3 Player Programmable School Broadcasting System
ITC T-6600 8*16 Matrix Internal MP3 Player Programmable School Broadcasting System
ITC T-6600 8*16 Matrix Internal MP3 Player Programmable School Broadcasting System
We’re proud to say that this host has complete function of PA system. It has both RS-422 and RS-485 and powerfully programmable automation control function. It’s integrated with multiple modules, such as 8*16 audio matrix, power manager, alarm signal receiver, scheduled tasks, etc. The high light is automatic addressing background music playing. When alarm signal input, every zones are turned to alarm mode. It’s suitable for small to large scale PA projects.
ITC T-6600 8*16 Matrix Internal MP3 Player Programmable School Broadcasting System
1) User-friendly: after installation, users only need to operate the whole system via the host
2) Automation control: It’s with 4 main program and each program has 200 steps; Also, 1 backup program is available for special occasions, like rainy days
3) 8*16 audio matrix: it could be operated manually or automatically
4) Each input has individual volume control; Applicable for various audio sources
5) It’s with MP3 player
6) Could control external audio player to achieve regularly targeted broadcast programs
7) It’s with internal 6 channel power sequencer and it’s expandable
8) Multiple modes of alarm: whole area alarm, partitions alarm, adjacent alarm, etc
9) Support local broadcast and paging
10) Working with remote paging console to achieve remote paging and broadcast
11) Support telephone paging
12) It’s with internal monitoring module to monitor designated input signal
ITC T-6600 8*16 Matrix Internal MP3 Player Programmable School Broadcasting System
Model |
T-6600 |
Power |
AC 110V@60Hz or AC 230V@50Hz |
Power Consumption |
30W |
Line Input |
10 Kohm 775mV unbalanced |
Line Output |
1 Kohm 0 to 1.5V unbalanced |
Frequency Response |
20 to 50KHz |
S/N Ratio |
90dB |
Distortion |
0.1% |
Level of Alarm Input |
0V |
Level of Alarm Output |
0V |
Level of Power Control Output |
0V |
Power of Monitoring Speaker |
0.5W |
Communication Port |
RJ45 |
Communication Protocol |
RS-422, RS-485 |
Communication Speed |
4800bps |
MP3 Storage |
SD |
Dimension |
484*350*132mm |
Weight |
7.62Kg |
