ITC T-6721 City Security 1 Key Get Helped IP Video Intercom China

ITC T-6721 City Security 1 Key Get Helped IP Video Intercom China photo-1
US$ 500 - 1,000 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ITC
Model Number:
T-6721
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shenzhen and HK
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name ITC
Model Number T-6721
Camera Other, CMOS
Power Other, AC 110 or AC 230V
Product Description

ITC T-6721 City Security 1 Key Get Helped IP Video Intercom China

Professional with Outdoor Camera push to help the network intercommunication terminal,Can be used with the remote video monitoring,Designed for safe city, a large park, tunnels, mines and other places design, at the same time can be used for broadcasting and background music.Can be fixed on the outdoor vertical bar.

Feature

ITC T-6721 City Security 1 Key Get Helped IP Video Intercom China

* Full metal jacket piano baking varnish craft,Explosion proof and waterproof housing,Durable,Can be fixed on the outdoor vertical bar.

* The equipment adopts the embedded computer technology and DSP audio processing technology design;Using high-speed chip industrial grade, starting time of less than 1 seconds.

* The built-in 1 road network hardware audio decoding module,Support TCP/IP, UDP, IGMP (multicast) protocol,To realize the network transmission of 16 bit stereo CD quality audio signal.

* The built-in voice intercom call module,Support full duplex voice intercom and call,High performance DSP audio processing collocation,Support digital echo cancellation, audio compression function.

* The built-in 5W high fidelity full frequency loudspeaker,Clear voice, loud;Built in 60W digital constant resistance power amplifier.Suitable for outdoor sound amplification demand.

* The built-in high-sensitivity microphone,Support for hands-free calls, support for custom answer mode, sound acquisition area wide, high degree of sound reproduction.

* The standard high-definition network camera, built-in double filter switching, support ONVIF protocol.

* Video support help linkage, figures moving equipment, mobile window function.

* To support the synchronization of video and audio storage function.

* The built-in monitoring function, support service level management of recording, built-in auxiliary audio IO, the perfect combination of monitoring system.

* With a short circuit input and a short circuit output terminal;Signal, data acquisition short-circuit input used in tunnel and other places;Short circuit output is suitable for city surveillance video linkage.

* Independent switch power supply, no radio or help, class D digital amplifier automatically enter the mute status.

* Built in a controllable power supply, for driving lights and other alarm equipment.

* Support for custom call target, support shortcut key, a key to call for help.

* Support a variety of communication strategy, including the call waiting, call forwarding, no answer to remind.

* Support the transfer time, no answer time, call waiting time custom.

* Support manual, automatic call transfer call phone function, can be set to call a phone number.

* Support preset quick playing program library, support network remote trigger program broadcast.

* Support for custom hanging mode, optional passive mode of active or hang up.

* Support PSTN phone broadcasting, voice broadcast messages of support.

* Support mobile phone WIFI VOD, wireless remote control on demand.

* High protection level (IP55) design, the overall use of alloy material and anti disassembling screw, and the explosion proof, waterproof, anti acupuncture.

* Support DHCP compatible routers, switches, bridges, gateway, Modem, Intelnet, 2G, 3G, 4G, multicast, unicast arbitrary network structure.

* Digital products, convenient expansion, is not limited by the geographical position, without the need to increase the management of computer room equipment, adopt the design idea of common network free line construction, easy to install.

Technical Parameter
Model
T-6721
Network Interface
RJ45
Communication Protocol
TCP/IP, UDP, IGMP multicast
Audio Format
MP3/MP2
Sampling Rate
8K-48KHz
Transmission Speed
100Mbps
Audio Mode
16 digit stereo CD sound level
Frequency Response
80Hz~16KHz
T.H.D
≤0.1%
SNR
>70dB
Working Temp
-20℃~60℃
Humidity
20%~80% Relative humidity, without condensation
Power Consumption
≤100W
Power Supply
~110V/60Hz or ~230V/50Hz
Protection Level
IP55
Dimension
365 x 580 x 80mm
Weight
10.5Kg
