Help CenterMINI HDMI Switch 3x1 3 Inputs 1 Output With IR Remote Control
Related Products
Specifications
MINI HDMI switch 3x1 3 inputs 1 output with IR remote control1. OEM
2. factory price
3. CE RoHS FCC
MINI HDMI switch 3x1 3 inputs 1 output with IR remote control
Introduction
The 3x1 HDMI Switcher allows access to multiple HDMI sources, using a single HDMI sink. The Switcher allows
three HDMI devices to be switched easily through one HDMI compatible monitor or projector. The Switcher can
also be placed at the end of a long HDMI cable to regenerate the HDMI signal.
Our devices offer solutions for noise, space and security concerns, data center control,
information distribution, conference room presentation, school and corporate training
environments.
Features
Three HDMI input signals switched to a single HDMI sink devices
Support deep color 30bit, 36bit
Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC
Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Support signal retiming
Support input up to 15metres AWG26 HDMI standard cable length,
output up to 25metres AWG26 cable length
Inputs can be switched with the IR remote control,also can be controlled by button.
It can smartly jump over those input sources which are not connected.
No loss of quality
Installs in minutes
Specifications:
HDMI resolution ………………………....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format …………………………..…………….24bit/deep color 30bit,36bit
Support audio format……………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Max bandwidth……………………………………………………………………………250MHz
Max baud rate…………………….………………….……………………………………7.5Gbps
Input/Output TMDS signal ………….…………………………..………...0.5~1.5Volts p-p(TTL)
Input/Output DDC signal ……………………………………………..………… 5Volts p-p (TTL)
Input cable distance..…... ……………………….…….…≤15m AWG26 HDMI standard cable
Output cable distance…………………………..…….…...≤25m AWG26 HDMI standard cable
Max working current………………………………………………………………………...350mA
Operating Temperature range……..…………….………………………………… (-15 to +55°C)
Operating Humidity range………………………….….……….5 to 90%RH (No Condensation)
Dimension (L x W x H) ……………………………….….………………………77x45x15 (mm)
Weight…..…………………………………………………………..……………………………..35g
