Specifications
1. mini HDMI Switch 3x1 with IR Remote Control ,Deep Color2. 3DTV Pass-Through
3. Resolutions up to 1080P
4. 3 in 1 out
Mini 3x1 HDMI Mechanical Switch 3D 1080P
The 3x1 HDMI Switcher allows access to multiple HDMI sources, using a single HDMI sink. The Switcher allows three HDMI devices to be switched easily through one HDMI compatible monitor or projector. The Switcher can also be placed at the end of a long HDMI cable to regenerate the HDMI signal.
Our devices offer solutions for noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
l Three HDMI input signals switched to a single HDMI sink devices
l Support deep color 30bit, 36bit
l Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC
l Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
l Support signal retiming
l Support input up to 15metres AWG26 HDMI standard cable length,
output up to 25metres AWG26 cable length
l Inputs can be switched with the IR remote control,also can be controlled by button.
l It can smartly jump over those input sources which are not connected.
l No loss of quality
l Installs in minutes
HDMI resolution ………………………....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format …………………………..…………….24bit/deep color 30bit,36bit
Support audio format……………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Max bandwidth……………………………………………………………………………250MHz
Max baud rate…………………….………………….……………………………………7.5Gbps
Input/Output TMDS signal ………….…………………………..………...0.5~1.5Volts p-p(TTL)
Input/Output DDC signal ……………………………………………..………… 5Volts p-p (TTL)
Input cable distance..…... ……………………….…….…≤15m AWG26 HDMI standard cable
Output cable distance…………………………..…….…...≤25m AWG26 HDMI standard cable
Max working current………………………………………………………………………...350mA
Operating Temperature range……..…………….………………………………… (-15 to +55°C)
Operating Humidity range………………………….….……….5 to 90%RH (No Condensation)
Dimension (L x W x H) ……………………………….….………………………77x45x15 (mm)
Weight…..…………………………………………………………..……………………………..35g
