Specifications
4:2 hdmi matrix promotion hot selling1. Ultra 4Kx2K and 1080P Full HD
2. with SPDIF (optical & coaxial) output port
hdmi 1.4 matrix china supplier
(1) It is a 4x2 HDMI matrix, 4 HDMI input and 2 HDMI output , any input to any output
(2) And you can also get audio ( split Toslink and 3.5mm stereo audio from output HDMI A port) ,and we do EDID audio setting ( ADV / 2.0CH / 5.1CH)
(4)The HDMI Input 1 support MHL/HDMI double mode input , that mean you can connect your MHL smart mobile phone ( such as Samsung SII , SIII,SIIII) with the MHL- HDMI cable we put with the device to the 4x2 HDMI matrix and then connect to the HDTV.
Routes four Ultra Hi-Def sources to two Ultra HD displays simultaneously.
l Supports resolutions up to Ultra HD 4K x 2K (3840 x 2160 @ 30Hz) and 1080p Full HD
l Supports 36 bit Deep Color
l Supports PCM , Dolby Digital™, and DTS Digital Surround™ ®
l Audio SPDIF(Coaxial and optical ) signal output and Output A signal is simultaneous.
l Support HDMI input/output cable 10 to 15 meters at 1080p/8-bit resolution
l Input port 1 is compliant with HDMI1.4/MHL2.0 specification
l Support CEC function (including Input port 1-4 and Output A)
l Support HDCP 1.3 specification
l Support HDMI1.4 ARC(Audio return channel) RX (Output A)
l 3DTV pass-through
l IR remote control
l Surface-mounting ear
Operating Temperature Range |
-5 to +35°C(+23 to +95°F) |
Operating Humidity Range |
5 to 90%RH (No Condensation) |
Bandwidth frequency |
10.2Gbps |
Input ports |
4xHDMI (female) |
Output ports |
2 x HDMI outputs 1x Optical audio output 1x Coaxial audio output |
Resolution outputs |
up to 4K x 2K (3840 x 2160 @ 30Hz) |
Dimensions (HxWxD) |
28x230x87mm |
Power consumption |
5W(MAX) |
Transmission Distance |
15m(Maximum)over standard HDMI cable/26AWG |
Net Weight |
510g |
