Specifications
Forming machine1. Japan Yuken valve
2. Forming, reduce, expand and wrinkle
3. PLC control
4. CE,ISO9001
Double-head automatic hydraulic metal steel and aluminum pipe and tube end forming machines machinery
Our company:
We are speciallzed in pipe bending machine,pipe ending forming machine, pipe rolling machine,pipe cutting machine and pipe chamfering machine. Our products are wildly used for automative industry, shipbuilding industry, the boiler industry,fitness equipment ,bicycles ,electric cars,motorcycles ,furniture industry and so on.
Main parameter:
| Specification/model | TM40 | TM60 | TM80 | TM100 | TM110 |
| Max bending capability | Φ40×2.0t | Φ60×2.0t | Φ80×2.0t | Φ1000×2.0t | Φ110×2.0t |
| Max working length | 100mm | 130mm | 150mm | 150mm | 150mm |
| Oil pressure | 12Mpa | 12Mpa | 12Mpa | 14Mpa | 14Mpa |
| Working speed | 100mm in 3-4sec | 100mm in 3-4sec | 130mm in 5-6sec | 140mm in6-7sec | 140mm in 8-9sec |
| Machine size | 200×55×130cm | 200×60×140cm | 290×70×140cm | 300×75×150cm | 350×90×180cm |
| Machine weight | 1100kg | 1250kg | 1600kg | 1800kg | 2500kg |
| Notes | The length of pipe according to customer | ||||
Features:
Forming machine
The machine is controlled by the computer, hydraulic drive, English screen display, man and machine dialogue operation, can choose manual. semi-automatic operation mode, movable pedal switch have start and emergency stop function.
Two position configuration: can reduce two times together, use the line guide as its carrier, makes its operation free abrasion, good repetition.
Process shapes: protrude, concave, joint, square, V type, and so on. Just according to the customer's requirements.
Can according to the pipe's length and adjust the diatance of machine head.
Can according to the pipe's length and choose single clamping and double clamping.
Can process the pipetwo ends, high efficiency, high accuracy.
Process pipe length can according to the customer's requirement.
Can choose kinds of clamping methods and ensure the processing pipe is tightened.
Hydraulic synchronic system, make sure the processing accuracy.
Use Japan Yuken valve.
The machine is convenient operation, stable function, high safe factor, is the perfect equipment for the pipe processing.
Inquiries are welcome at any time.
Photos of machines:
