LM1450 Universal Milling Machine
Product Description for LM1450 Universal Milling Machine
LM1450 is a vertical-horizontal universal milling machine, large travel. Z-axis can be manually, up to 600MM good stability, power feed on two axes, motorized lift on z axis, three axes hardened.
The fuselage and the lifting platform for the square guide, the longer of the slider to enhance the stability of the table travel.
Spindle taper |
ISO40(ISO50)(H) |
Max end milling (mm) |
125(V) 100(H) |
Swivel angel milling head |
360° |
Rang of spindle speed(r.p.m) |
35-1600(V) 40-1300(H) |
Distance from spindle to table (mm) |
150-600 |
Distance from spindle to column(mm) |
760 |
Table size (mm) |
1250*360 |
Table travel (mm) |
1000*300*390 |
T-slot (number/width/distance) |
3/18/80 |
Main motor power(kw) |
3 |
Overall dimension(mm) |
1550*1670*1950 |
Weight(kg) |
2650/2850 |
Advantage:
1.Cast iron with high precision, long service life
2.High strength milling head very flexible,long service life
3. Feeding gear box maintenance convenient, practical
4. Three axis hardening treatment, rectangular guideway
Production&Workshop for LM1450 Universal Milling Machine
Packaging&Shipping for LM1450 Universal Milling Machine
Companny information for LM1450 Universal Milling Machine
Lianyungang Linuo Machine Tool Co.,ltd is a leading high-tech enterprise and manufacture in China for High end machine tools, has strong technical team covering full technical field.
which is specializes in exporting all kinds of machinery,such as grinding machines,CNC machine centers,CNC & universal lathes,CNC & universal milling machines,radial drilling machines,and cnc wire cutting edm machines,bandsaw machines etc.
Lianyungang Linuo Trading Co.,ltd is a Import & Export company,which is the branch company for international business.
We sincerely hope to establish a long-term cooperative relationship with you and become your true partner when you need our service.
Our services for LM1450 Universal Milling Machine
1. Technical support online service provided.
2. Technical files service provided.
3. On-site training service provided.
4. All of the questions will be replied within 24 hours
5. Warranty period: one year
During warranty period, if you have any parts broken because of qulity problem,we will supply to you free of charge by express.
Out of warranty period, if you have any question, you can contact with us, we will supply our best service to you.
