Elastic / Stretch Film Machine

Elastic / Stretch Film Machine photo-1
US$ 5,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Commodity
Packaging Type:
Other, Wooden case
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Commodity
Packaging Type Other, Wooden case
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Power 360V
Place of Origin Shanghai, China
Brand Name TL
Model Number TL-A1000

Specifications

1,adopts advanced technology with timing improvement.
2,Full-frequency conversion control and stable operation, high efficie



Main features

  1,adopts advanced technology with timing improvement.
  2,Full-frequency conversion control and stable operation, high efficiency, low energy consumption
  3,stretch film produced in one process
  4,applicable to producing Double-sided sticky stretch film
  5,remainings can be recycling

Equipment introduction
These series are mainly used to produce one-way stretch PE film (stretch film, wrapping film), and fresh-keeping Film. The production of the film has viscosity on one side or both sides which can be widely used in packaging of building materials, hardware accessories, etc. The screw and its canister are made of 38 Al-Cr-Mo alloy and nitrogen processed. They are of high hardness, strong erosion resistance and endurance. Advanced automatic control system for temperature control, T type die adopts multi-point adjustment, so that ensures a more uniform thickness of membrane material. Recycled water cooling device supplies good cooling effect. Rolling device adopts the friction-type winding, and equipped with edge-cutting devices and remaining recycle device makes the film rolled more neatly.
Mode SLW-600stretch film machine SLW-1000stretch film machine
Screw diameter 55mm 60mm
L/D ratio 28:1 28:1
Screw Barrel Material 38CROMLA 38CRMOLA
Die width 750mm 1250mm
Film width 600mm 1000mm
Film thickness 0.01 -0.5mm 0.01 -0.5mm
Roller diameter 300mm 300mm
Output 30kg/h 50kg/h
Main Motor power 11kw 7.5KW × 2
Heating power 15kw 25kw
Overall dimension 6000 × 1500 × 2500mm 6000 × 2000 × 2500mm
