Compatible Huawei GPON Onu Optical Splitters PLC FBT 1x2 1x4 1x8 1x16

Name: Compatible Huawei GPON Onu Optical Splitters PLC FBT 1x2 1x4 1x8 1x16
Brand: Atongda OEM
SKU: 114820971

US$ 1 - 10 MOQ: 20 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Atongda OEM

Model Number:

ATD- PLC Splitter 1x8

Shenzhen Atongda Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Atongda OEM

Model Number ATD- PLC Splitter 1x8

Compatible GPON Optical Splitters PLC FBT 1x2 1x4 1x8 Fiber Optic Splitter

Application Scope:

1) FTTX (FTTP, FTTH, FTTN, FTTC)

2) Passive Optical Networks (PON)

3) Local Area Networks (LAN)

4) CATV Systems

5) Test Equipment

Features&Advantage:

High uniformity

Easy Installation

High reliability

Comply with GR-1221 and GR-1209

Various coupling ratio

Single mode and multi mode available

Low PDL, low excess loss, low insertion loss

Environmental stable

Standard type, compact size

Variety of connectors available

Adjustable

PLC Splitter specification (room temperature,without connector insertion loss)

Parameter		Specification
Operating Wavelength(nm)		1260~1650
Type		1*2	1*4	1*8	1*16	1*32	1*64	2*2	2*4	2*8	2*16	2*32	2*64
Insertion Loss(dB)	Typical	3.6	6.8	10.0	13.0	16.0	19.5	4.0	7.0	10.5	13.5	16.5	20.5
Insertion Loss(dB)	(P/S) Max	3.8/4.0	7.1/7.3	10.2/10.5	13.5/13.7	16.5/16.8	20.5/21.0	4.1/4.3	7.4/7.6	10.8/11.0	14.3/14.5	17.3/17.5	20.7/21.5
Uniformity(dB)	Typical	0.4	0.5	0.5	1.0	1.0	2.5	0.6	0.8	1.0	1.5	2.0	2.0
Uniformity(dB)	Max	0.6	0.6	0.8	1.2	1.5	2.5	0.8	0.8	1.5	2.0	2.5	2.5
PDL(dB)Max.	Typical	0.1	0.1	0.1	0.2	0.2	0.2	0.1	0.1	0.1	0.2	0.2	0.2
PDL(dB)Max.	Max	0.15	0.15	0.25	0.3	0.3	0.3	0.2	0.2	0.3	0.4	0.4	0.4
Wavrelength department loss(dB)	Typical	0.1	0.1	0.1	0.1	0.2	0.2	0.1	0.1	0.1	0.1	0.2	0.2
Wavrelength department loss(dB)	Max	0.2	0.2	0.3	0.5	0.5	0.5	0.2	0.2	0.3	0.5	0.5	0.5
Temperature department loss(dB)	Typical	0.3	0.3	0.3	0.4	0.4	0.4	0.3	0.3	0.3	0.4	0.4	0.4
Temperature department loss(dB)	Max	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5
Directivity(dB)Min		55
Return Loss(dB)Min		55(50)
Operating Temperature(℃)		-40~+85
Storage Temperature(℃)		-40~+85
Fiber Length		1m or client requirments
Fiber Type		ITU G652.D /G657.A
Connector Type		client requirements
