Gigabit ethernet optical fiber switch 1000Mbps
2 rj45 ports & 4 sfp sockets
Description
ATD-G420 Gigabit Ethernet Switch with two10/100/1000M UTP port sand four fiber ports Or four 1000M SFP sockets
(The end users can usedifferent SFP Module according to his requirement,for example:1000Base-T,1000Base-SX,1000Base-LX etc.The product is possessed of stable performance,excellent quality and reasonable price because
of adopting latest IC from USA and high quality of transceivers.It is applicable to use in small patterns of Optical Fiber Ethernet.
Features:
1. 2 RJ45 ports and 4 LC fiber ports or 4 SFP sockets,
2.It can convert Optical Electric Ethernet signals between 10/100/1000M UTP ports and 1000M optical fiber ports and switch Ethernet signals between port and port.
3.Auto negotiation function supports UTP ports to auto 10/100/1000M and Full Duplex/Half Duplex.
4. Broadcast storm protection
5. Supports VLAN and QoS
6. Supports the max1536 bytes frame
7. Small power consumption(3W),low heat,good stability
Specifications
Standard Protocol |
IEEE 802.3 10Base-T |
|||
IEEE 802.3u 100Base-TX | ||||
IEEE 802.3ab 1000Base-T | ||||
IEEE802.3z 1000Base-SX/LX | ||||
Band Width |
RJ 45 Port: 10/100/1000Mbps |
Optical Port: 1.25Gbps |
||
Operation Mode |
Full /Half duplex mode |
|||
Connectors |
UTP: 2 RJ-45 |
Fiber connector: SC/LC |
||
Operation Mode |
Full /Half duplex mode |
|||
Power Supply |
External |
AC110-250V/50Hz |
||
DC 5V 2A | ||||
Power Consumption |
≤5W |
|||
Environmental Parameters |
Work Temperature |
0℃~50℃ (32 °F ~ 122 °F ) |
||
Storage Temperature |
-40℃~70℃ (-40 °F ~ 158 °F ) |
|||
Humidity |
5%~90% non-condensing |
|||
TP Cable |
Cat5 UTP cable (the max distance up to 100m) |
|||
Fiber Cable |
8. 3/125, 8. 7/125, 9/125, 10/125μm(the max distance up to 20 -120km) |
|||
50/125, 62. 5/125μm(the max distance up to 2km or 5km) | ||||
MTBF (Hours) |
>50000 |
|||
Dimensions(mm) |
External power supply |
155mm*90mm*27mm |
||
Gross Weight |
External power supply |
0.5kg |
||
Emission/Safety |
FCC Part 15 , Class A, RoHS and CE Mark |
|||
