Unique and beautiful looking design good heat dissipation performance recessed high power led grille lamp
- 5000 Piece / Pieces per Month
- shenzhen/guangzhou
- Credit Card PayPal
- Grille Lamp 3x28W High Quality Ceiling Louver Panel Light
- Top Quality 120x60 T8 Grille Lamp 40W LED Light Panel
- Double Sided LED Tube LED Light Panel Rechargeable LED Light Grille Lamp
- 60x60 Grille Louver Ceiling Light T8 Fluorescent Fitting With Transparent Diffuser
- High Quality T8 LED Clear Diffuser lumInaries With Acrylic Diffuser Clean Room Grille Light
- Troffer Lights Louver 2X14W Light Fixture Indirect Troffer Grille Light
Product Details
LED Light Source: | CREE chips | Grid Shape: | Other, square | Input Voltage(V): | 220 |
Lamp Power(W): | 45 | Lamp Luminous Flux(lm): | 3600 | Lamp Luminous Efficiency(lm/w): | 80 |
Color Temperature(CCT): | Other, 3000k/4000k/5000k | Working Temperature(℃): | -20, 60 | Working Lifetime(Hour): | 50000 |
Lamp Body Material: | Aluminum | Certification: | CE, EMC, LVD, UL | Place of Origin: | Guangdong, China |
Brand Name: | UPL | Model Number: | UPL-GDL-1X45W-B |
Product Description
Item name: Unique and beautiful looking design good heat dissipation performance recessed high power led grille lamp.
Features
-Highly cost-effective.
-Can replace the conventional downlights
-Material: Aluminium & Glass
-High Brightness Original American Bridgelux COB LEDs
-Efficient Heat Dissipation with fan
-Gimbal
-New & nice design
-Good packing
-Low heat, No UV,No IR. High CRI
-Life Span: 50,000 hours
-Standard Warranty: 3 Years
-Housing color: White or Siliver
Specification
Name | COB LEDs GRILLE DOWN LIGHT |
Model | UPL-GDL-1x45W-B |
Working-voltage | AC100-240V,50-60Hz |
Power | 45w |
Light source | CREE LEDs |
Lumens | 3600LM |
Color temperature | 3000K/4000K/5000K |
Color rendering | Ra>80 |
Bean angle | 15°/24°/36° |
Operating temperature | (-20℃~60℃ |
Strorage temperature | (-30℃~80℃ |
Dimmability | Optional |
IP grade | IP20 |
Life-span | 50000hours |
Guaranty | 3years |
Certificates | CE & ROHS,UL |
Housing color | White, Black, Grey |
Lamp dimension | L176*W176*H145mm |
Hole cut size | L157*W157mm |
Net weight | 1.1kgs |
Packing inner box | L225*W225*H215mm |
Packing outer carton | L465*W465*H450mm, 8pcs/carton, GW 12.8kgs |
Packing marterial | Carton |
Luminaire photometric test report
Product Display
More LED Grille downlight series
Applications
About Us
UPL is short for Uniled Professional Lighinting Co.,Ltd.
Since 2005,Uniled Professional Lighting Co.,Ltd. has been specializing in LED lighting products.Our products exported to more than 30 countries,such as Autralia, Finland, Norway, Germany,UnitedKingdom, Newtherland,France,Spain,Italy,USA,etc.
With many years business cooperation with customers,UPL has established partnerships with French, Australian, Norway and United Kingdom,etc.More customers are welcomed to make long time cooperation with UPL. UPL recent project reference: Volkswagen showroom, Mercedes Benz showroom, Toyota showroom, Honda showroom, New Zealand banks, French LECLERC supermarkets, BMW, Mercedes Benz, Carrefour chain supermarket, German Fashion hair dressing.
UPL suppports customers successfully work on 5-star hotels,big factory lighting replacement,car packing lot lighting replacement and goverment projects,such as gas station,airport,schools,city halls,etc.
UPL LED lighting products are with international certificiates,such as CE& ROHS.Moreover, UPL implements 58 Managerments strictly in producing and quality inspecting,which makes UPL win a great reputation from customers.
Why choose UPL?
1. More than 9 years experience in Led manufacturing
2. Establish long term stable cooperation with many renowned enterprises
3. Know well about high quality requested markets
4. Strict procedure quality supervising and burn-in period
5. Complete Quality Control System
6. Good after-sales service
Welcome to Visit Our Factory
CE & RoHS Certificates
Notice
1. Pay attention to the voltage before using
2. Check the connection between drivers & lamps
3. Turn off the power before connection
Trade Terms
1. Payment: T/T only 30% deposits before production, 70%balance to be paid before deliver (Western Union or T/T are welcomed)
2. Production Lead Time for 100~500pcs: 20-25 work days
3. Sample can be delivered in 7 work days
4. Shipping freight are quoted under your requests
5. Shipping port: Shenzhen or Guangzhou, Mainland China
6. Discounts are offered based on order quantities
Shipping ways
Samples for testing is welcome
